Bisco Self-Clinching Blind Stud 1/2-30 Thread, 20mm Length
Enhance assemblies with Bisco Self-Clinching Stud – steel construction, corrosion-resistant plating, and secure fastening. Ideal for various applications.
US
In stock
About Product
Upgrade your assembly projects with the Bisco Self-Clinching Blind Stud featuring a 1/2-30 fine thread size and a sturdy steel construction. This stud ensures secure fastening with a flange diameter of 17.7mm and can be used on materials with a thickness ranging from 0.7mm to 3mm. The zinc plating with clear trivalent passivation offers excellent corrosion resistance, making it ideal for various applications. With a spline length of 5.65mm and a steel grade of 8, this stud provides reliable performance and durability.
Additional information
| Specifications Brands | |
|---|---|
| Specifications Thread Size | |
| Specifications Can Diameter | |
| Specifications Material | |
| Specifications Fastener Type | |
| Specifications Length | |
| Specifications Plating Finish | |
| Specifications Spline Length | |
| Specifications Steel Grade | |
| Specifications Treatment |
Key Specifics
- Specifications
- Brands: Bisco
- Sheet Hole Size: 6.9 to 8.9 mm
- Thread Size: 1/2-30
- Overall Head Height: 10.85 mm
- Can Diameter: 13.3 mm
- Flange Diameter: 17.7 mm
- Material: Steel
- Material Thickness: 0.7 to 3 mm
- Fastener Type: Self-Clinching
- Length: 20 mm
- Plating Finish: Zinc and Clear Trivalent Passivation
- Spline Length: 5.65 mm
- Steel Grade: 8
- Thread Coarseness: Coarse
- Tonnage Typical: 5.0 to 10.0 mm
- Treatment: Passivated
