AISI 304 Stainless Steel (18-8) Type "AB" Flat Phillips® Drive Self-Tapping Sheet Metal Screw

AISI 304 Stainless Steel (18-8) Type "AB" Flat Phillips® Drive Self-Tapping Sheet Metal Screw

SCR-5d7344

N/A

$49.99
$49.99
Sale

Initiate Order

AISI 304 Stainless Steel (18-8) Type "AB" Flat Phillips® Drive Self-Tapping Sheet Metal Screw

AISI 304 Stainless Steel (18-8) Type "AB" Flat Phillips® Drive Self-Tapping Sheet Metal Screw

$49.99

Quantity: 1

Claim Your Seller Account

AISI 304 Stainless Steel (18-8) Type "AB" Flat Phillips® Drive Self-Tapping Sheet Metal Screw

AISI 304 Stainless Steel (18-8) Type "AB" Flat Phillips® Drive Self-Tapping Sheet Metal Screw

$49.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
Sheet Metal Screws, or Self-Tapping Screws, are thread cutting fasteners designed to be driven into untapped holes. They generally require a pre-drilled pilot hole (drill size dependent on the screw diameter and material thickness). They are available with a variety of points and thread styles in order to accommodate different material thickness.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Additional Information
Also known as self-tapping screws, these are mostly used in thin gauge sheet metal applications.Type "AB" sheet metal tapping screws feature a sharp point and fine threading.Flat countersunk head screws sit flush with the surface of the material they are inserted into.Type 304 stainless steel is defined as a Chromium-Nickel austenitic alloy.Stainless steel significantly improves resistance to tarnishing or corrosion.
Specifications Coating
Uncoated
Specifications Drive Detail
Phillips® Type H
Specifications Drive Style
Cruciform Recess Drive
Specifications Head Detail
82 Degree Countersink
Specifications Head Style
Flat Countersunk Head
Specifications Industry Standards And Specifications
American Society of Mechanical Engineers (ASME B18.6.3)
Specifications Material
Stainless Steel
Specifications Material Grade
AISI 304 Stainless Steel (18-8)
Specifications Style
Type "AB"
Specifications System Of Measurement
Inch
Specifications Thread Direction
Right-Hand Thread
Specifications Thread Length
Full Thread
