Cablecraft® Unidrum Lever Control Specialty Cable - Utility Series
Cablecraft® Unidrum Lever Control Specialty Cable - Utility Series
SKU:PUS-5df889
Enhanced Cablecraft® Unidrum Lever Control Cable for precise utility applications. Black knob color, grooved swivel output, and 2" cable travel.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Cablecraft® Unidrum Lever Control Specialty Cable - Utility Series
$89.99
Quantity: 1
Claim Your Seller Account
Cablecraft® Unidrum Lever Control Specialty Cable - Utility Series
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Cablecraft® Unidrum Lever Control Specialty Cable in the Utility Series offers precise control and durability for light lever applications. Featuring a Black knob color, a grooved swivel output end configuration, and an upper mount with a right exit cable position, this cable ensures smooth operation with a travel distance of 2 inches. With an overall length of 120 inches and a swivel dimension of 2 to 6.25 inches per stroke, this cable meets the demands of various utility applications.
Product Specifications
Specifications Cable Exit Position
CableCraft Unidrum Lever Upper Mount, Right Exit
Specifications Cable Travel
2 "
Specifications Knob Color
Black 165-505-101
Specifications Lever Travel
Approx. 90º
Specifications Output End Configuration
Grooved Swivel
Specifications Overall Length In
120 "
Specifications Swivel Dimension A Per Stroke
2 to 6.25 "
Specifications Swivel Dimension A Per Stroke Extended
3 to 8.25 "
Specifications Type
Utility
Specifications Wire Rope Dia
Very Light Duty
