Check-All® 2" Nominal Pipe Size WV Style Wafer Insert Check Valve
Check-All® 2" Nominal Pipe Size WV Style Wafer Insert Check Valve
SKU:WVS-fc6709
Discover reliable Check-All® 2" Nominal Pipe WV Style Wafer Insert Check Valve crafted with 316 Stainless Steel & Standard Cracking Pressure of 1.50 psi.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
Check-All® 2" Nominal Pipe Size WV Style Wafer Insert Check Valve
$349.99
Quantity: 1
Claim Your Seller Account
Check-All® 2" Nominal Pipe Size WV Style Wafer Insert Check Valve
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Check-All® 2" Nominal Pipe Size WV Style Wafer Insert Check Valve is expertly designed to seamlessly fit between ANSI flanges, offering quick installation and removal in rigid piping applications. This valve is crafted with high-quality 316 Stainless Steel for durability and reliability. Its Standard Cracking Pressure of 1.50 psi ensures precise and efficient operation. With options like Metal-to-Metal, Buna-N, and PTFE Seat Materials, this valve caters to various needs. Certified to meet European Conformity (CE) PED 2014/68/EU and ISO 9001 standards, this Made in USA valve is a top choice for industrial applications.
Product Specifications
Note
Made in USA.
Specifications Body Material
316 Stainless Steel = SS | 316L Stainless Steel = SS | Alloy 20 = A2 | Alloy B = HB | Alloy C-276 = HC | Brass = BR | Carbon Steel = CS | Monel® 400 or Alloy R405 = MO | Titanium = TI
Specifications Certifications
European Conformity (CE) PED 2014/68/EU Complaint | International Organization for Standardization (ISO 9001) Certified
Specifications Nominal Pipe Size
2 in
Specifications Non Shock Pressure Rating
American National Standards Institute (ANSI) Class 150 - 1500
Specifications Non Shock Pressure Rating At 100 Degree Fahrenhei
1500 psig
Specifications Non Shock Pressure Rating For Brass Valves
American National Standards Institute (ANSI) Class 150 - 300
Specifications Seat Material
"Metal-to-Metal" = MT | Aflas® = AS | Buna-N = BN | Ethylene Propylene Diene Monomer (EPDM) = EP (EP seats not recommended for use with Carbon Steel valves.) | Fluoro-Elastomer (FKM) = VT | Neoprene = NE | Perfluoroelastomer = KZ | Polytetrafluoroethylene (PTFE) = TF
Specifications Size Code
K
Specifications Special Options
T = FEP Encapsulated Spring (Contact the factory for more options)
Specifications Spring Material
17-7PH Stainless Steel = PH | 316 Stainless Steel = SS | Alloy C-276 = HC | Inconel® X750 or Alloy X750 = IX | Monel® 400 = MO | Titanium = TI
Specifications Standard Cracking Pressure
1.50 psi
Specifications Valve Style
WV
