Donaldson® Torit® Downflo® Evolution 60 Dust Collector - 180in Dimension A
Donaldson® Torit® Downflo® Evolution 60 Dust Collector - 180in Dimension A
SKU:DOW-500b79
Upgrade to the Donaldson® Torit® Downflo® Evolution 60 Dust Collector for superior efficiency and space savings.
Regular price
$13,999.99
Regular price
Sale price
$13,999.99
Unit price
per
Initiate Order
Donaldson® Torit® Downflo® Evolution 60 Dust Collector - 180in Dimension A
$13,999.99
Quantity: 1
Claim Your Seller Account
Donaldson® Torit® Downflo® Evolution 60 Dust Collector - 180in Dimension A
$13,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Donaldson® Torit® Downflo® Evolution 60 Dust Collector sets a new standard in dust collection efficiency. With 60 filters and an impressive Ultra-Web® Filter Area of 15240 ft², this best-in-class collector reduces filter replacement costs by up to 40%. Its innovative design enhances manufacturing space utilization, making it ideal for Dry Bulk, Food Processing, and more. Meeting strict seismic, wind speed, and construction material standards, this collector ensures top performance and safety.
Product Specifications
Additional Information
A smaller collector helps lower the initial purchase price, reduces filter replacement costs, and opens up valuable manufacturing floor space.This state of the art collector, coupled with Donaldson®'s industry-leading Ultra-Web® nanofiber filtration technology, is truly an intelligent design.
Applications
Dry Bulk | Food Processing | Glass | Metal Grinding | Metal Manufacturing | Pharmaceutical | Plasma Cutting | Thermal Spray | Welding
Dimensions Dimension A
180.0 in | 4572.0 mm
Dimensions Dimension B
128 in | 3251.0 mm
Dimensions Dimension C
101 in | 2565 mm
Dimensions Dimension D
24.0 in | 36.0 in | 42.0 in | 48.0 in | 610 mm | 915 mm | 1067 mm | 1219 mm
Operating Conditions Alternating Current Ac Control Voltage
120 V
Operating Conditions Basic Wind Speed And Exposure C Per Interna
90 mph | 145 km/h
Operating Conditions Compressed Air Required
90 to 100 psi | 6.2 to 6.9 bar
Operating Conditions Direct Current Dc Control Voltage
24 V
Operating Conditions Housing Construction Material
Steel
Operating Conditions Housing Construction Material Thickness
3/16 in. (4.8 mm) to 10 Gauge
Operating Conditions Housing Rating
-25 to 10 inH2O | -635 to 254 mmH2O
Operating Conditions Operating Temperature
150 ºF | 66 ºC
Operating Conditions Seismic Spectral Acceleration S1 Per Intern
0.6 g
Operating Conditions Seismic Spectral Acceleration Ss Per Intern
1.5 g
Specifications Approximate Shipping Weight
7700 lb | 3493 kg
Specifications Inlet Size For 24 Inch In Dimension D
10 to 16 in
Specifications Inlet Size For 36 Inch In Dimension D
17 to 24 in
Specifications Inlet Size For 42 Inch In Dimension D
26 in | 28 in | 30 in | 32 in
Specifications Inlet Size For 48 Inch In Dimension D
34 in | 36 in | 38 in | 40 in | 42 in
Specifications Number Of Filters
60
Specifications Number Of Valves
30
Specifications Ultra Web Filter Area
15240 ft² | 1415.8 m²
