DP® 50 kW Hammer Mill
DP® 50 kW Hammer Mill
SKU:DPH-71da46
Enhance your processing efficiency with the DP® 50 kW Hammer Mill. Accurate, durable, and versatile for various applications.
Regular price
$13,999.99
Regular price
Sale price
$13,999.99
Unit price
per
Initiate Order
DP® 50 kW Hammer Mill
$13,999.99
Quantity: 1
Claim Your Seller Account
DP® 50 kW Hammer Mill
$13,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The DP® 50 kW Main Drive Motor Hammer Mill is a robust grinding mill designed for food, chemical, and pharmaceutical processing. Featuring a durable construction, this hammer mill offers improved grinding efficiency, fine reductions down to 50 microns, and low specific power consumption. With versatile applications such as Maize, Spices, Cattle feed, and more, it delivers accurate and consistent product grinding while ensuring reliable operation. Made in India, it is ideal for harsh environments and continuous duty use.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Additional Information Additional Information
This produces size reduction by impact. It consist of screen and integrated blower with individual driving motor for pneumatic conveying of material out of the grinding chamber.The DP® Hammer mills can be used for a wide range of applications in number of processing fields, e.g. Maize, Spices, Cattle feed & Poultry feed, Dry fish, Chemicals, Oil cake, Tea, Coffee, Crude drugs, Moulding powders, Dry soap, Charcoal.
Features And Benefits Features And Benefits
Hammer mill built with robust construction.Improved grinding efficiency.Capable of fine reductions down to 50 microns or 300 mesh.Low specific power consumption.Durable long life (Some 1970s and 80s models are still in use today).Accurate & consistent product grinding.Low temperature rise for heat sensitive materials.Available in abrasion resistant design for materials up to 6-7 Mohs hardness.Reliable operation due to robust design.Cool and gentle grinding due to high airflows.
Note Note
Made in India
Options And Accessories Options And Accessories
Machine Contact and Non-Contact Parts available in Cast lron, Carbon Steel, 304, 304L, 316, 316L Hard Alloy Steel Casting,Wearable parts available in hard materials like Forged Alloy Steel, Welded Hard Facing, Internal fan available in single or two piece designAvailable in external fan design where airflow control is requiredLiners available in water jacketed design to provide cooling in the grinding chamber
Specifications Air Flow Rate
5400 m³/h
Specifications Main Drive Motor
50 kW
Specifications Rotor Speed
4000 rpm
Specifications Scale Up Factor
2
