The DualVee® Size 2 Guide Rail is a durable solution designed for precise linear motion applications. Made of AISI 1045 Carbon Steel, this 48.63-inch guide rail features 17 hardened mounting holes for easy installation. Its induction hardening to Rc 53 ensures long-lasting performance, while the integrated mounting shoulder allows for accurate alignment. Ideal for use with DualVee® guide wheels, this polished and oiled guide rail offers customization options including black oxide, chrome, and nickel plating.
Product Specifications
Specifications Circuit
SPDT DB
Specifications Constructionstandards
NEMA Type 2, 4 & 13UL Enclosure 2, 4 & 13CSA Enclosure 2, 4 & 13EN 60529 Degree of Protection IP56
Specifications Electrical Rating
Heavy pilot duty 250 Vac max. | 1/2 H.P. 125 VAC | 1 H.P. 250 VAC | 15A 125-250 VAC
Specifications Features
DriptightDusttightWatertightOiltight
Specifications Form
Z
Specifications Remarks
DB Double break model must be wired to equal voltage sources and the same polarity. The loads should be on the same sides of the line.
Specifications Size
9 x 5 3/4 x 4 3/4 Inch
Specifications Stages
Two
Specifications Weight Approx
8 lbs
