Hernon Ammunition Sealant 76060 Grade
Hernon Ammunition Sealant 76060 Grade
High-performance ammunition sealant for quick, efficient, and military-grade sealing of primers and case mouths.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Hernon Ammunition Sealant 76060 Grade
$49.99
Quantity: 1
Claim Your Seller Account
Hernon Ammunition Sealant 76060 Grade
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Hernon®'s 76060 Grade Ammunition Sealant offers advanced formulation technology with dual UV and anaerobic curing mechanisms for sealing primers and case mouths efficiently. This light yellow, medium-strength sealant provides robust resistance to solvents, heat, and environmental factors, ensuring integrity under various conditions. With rapid UV curing in 3-7 seconds, this sealant enables quick handling or packaging. Hernon®'s dedicated technical support and customizable options make it ideal for diverse ammunition types, meeting military-grade standards and surpassing U.S. MIL-SPEC and NATO waterproofing standards.
Product Specifications
Additional Information Additional Information
Customizable Options: Available in an array of colors and strengths to meet specific requirements for bullet pull strengths or aesthetic preferences.Versatile Use: Ideal for a range of ammunition types including blank rounds, shot shells, grenade fuses, large caliber components and more.Military Grade Standards: Rounds sealed with Hernon® ammunition sealants surpass U.S. MIL-SPEC and NATO standards for waterproofing.Advanced Sealing Technology: Offers a more effective sealing solution compared to traditional asphalt sealing methods.
Application Equipment Application Equipment
Integrated R&D Synergy: Hernon®'s in-house chemical and equipment R&D teams collaborate closely, ensuring customers have access to both the most suitable sealant formulations and the most efficient and effective application systems.Precision Dispensing and Curing: Designed to precisely seal and UV cure sealant on ammunition primers and/or case mouths, ensuring consistent quality and accuracy.Automatic Application Systems: Transition from a labor-intensive, batch sealing process to a streamlined, clean and continuous sealing operation with our automatic application systems.Advanced Equipment Options: Utilize Hernon®'s Sureshot® 3510 microjet dispensing valves and Ultracure® UV curing lights for optimal performance.Comprehensive System Solutions: Offers additional options like 100% vision inspection, automatic bowl feeders, elevators for bulk loading and more, enhancing the sealing process.Flexible Sealing Capabilities: Hernon® are experts in designing and building systems for a wide range of production speeds from 20ppm standard equipment to fully custom systems sealing up to 2000ppm.Customization Expertise: Hernon® specializes in crafting custom-designed application equipment and components for scenarios where standard solutions fall short in efficiency or effectiveness.Dedicated Technical Support: Provides in-house and remote technical support for equipment setup and troubleshooting, ensuring seamless operation and maintenance.
Common Criteria For Choosing The Optimal Grade Of Ammunition Sea
Choosing the correct sealant characteristics can help achieve ideal bullet pull strength and standard deviation between roundsThe "cleanliness" of rounds at the time of sealing is significant. Rounds with contaminants (ie: lubricants, grease, etc.) will have lower surface energy. Rounds with lower surface energy tend to require sealants with lower surface free energy to achieve full coverage.Lower viscosity sealants have better wicking and penetrating characteristics while higher viscosities offer higher strengths and hardness after curedSmaller caliber rounds tend to have tighter gaps and experience better sealing results with lower viscosity sealants which penetrate better. However, larger caliber rounds provide more sealant options to choose from depending on the manufacturer's desired results.
Note Note
Contact Hernon® to discuss which grade would be the best solution for your specific requiremnets!The data presented in these graphs was derived from extensive internal testing, is furnished for information purposes only and is believed to be reliable. It is important to note that pullout force results, while comprehensive, are subject to variability based on the specific components used as well as other variables that are beyond our control. While these results offer valuable insights, they should be considered indicative and may vary in different practical scenarios. We cannot assume responsibility for the results obtained by others over whose methods we have no control.
Technical Specs Brands
Hernon Manufacturing, Inc
Technical Specs Color
Light Yellow
Technical Specs Grade
76060
Technical Specs Strength
Medium
Technical Specs Surface Tension
29.0 mN/m
Technical Specs Viscosity At 25 Degree Celsius C Temperature
5 to 20 cP
