Hilna™ GPS C034 Ruggedized Low Noise Amplifier
Hilna™ GPS C034 Ruggedized Low Noise Amplifier
SKU:HIG-783334
N/A
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Hilna™ GPS C034 Ruggedized Low Noise Amplifier
$49.99
Quantity: 1
Claim Your Seller Account
Hilna™ GPS C034 Ruggedized Low Noise Amplifier
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
This high-performance module delivers 32 dB of gain across the frequency range of 1200 MHz to 1600 MHz with an OIP3 of +30 dBm and less than 1 dB of noise figure. The HILNA GPS C034 is also usable up to 2000 MHz with 28 dB of gain (typical). NuWaves’ HILNA GPS C034 is a ruggedized, broadband low noise amplifier designed to achieve high gain while maintaining low noise and a high third order intercept point specifically for L1 (1575.43 MHz) and L2 (1227.6 MHz) GPS signals. The HILNA GPS C034’s robust power supply also operates over a very broad range easily allowing the unit to be integrated into systems without regard to power supply precision.
Product Specifications
Specifications Export Classification
EAR99
Specifications Gain Typ
32 dB
Specifications Input Supply Vdc
22 - 34
Specifications Maximum Frequency
1600 MHz
Specifications Minimum Frequency
1200 MHz
Specifications Noise Figure Typ
0.8 dB
Specifications Size Lx W X H
3.27 x 3.76 x 0.95 Inch
Specifications Weight
6.9 oz
