MARTIN® IN-LINE Chevron Belt Cleaner for Belt Conveyors
MARTIN® IN-LINE Chevron Belt Cleaner for Belt Conveyors
SKU:BEL-cc3fb7
Efficiently remove carryback with MARTIN® IN-LINE Chevron Belt Cleaner for ribs, chevrons, and cleats. Durable and easy maintenance.
Regular price
$499.99
Regular price
Sale price
$499.99
Unit price
per
Initiate Order
MARTIN® IN-LINE Chevron Belt Cleaner for Belt Conveyors
$499.99
Quantity: 1
Claim Your Seller Account
MARTIN® IN-LINE Chevron Belt Cleaner for Belt Conveyors
$499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MARTIN® IN-LINE Chevron Belt Cleaner is a high-performance solution designed to effectively remove carryback from belts with ribs, chevrons, and cleats. Utilizing rubber or urethane blades, this cleaner ensures thorough cleaning while minimizing belt wear. Equipped with 30°-offset arms, the MARTIN® TORSION ARM™ technology enhances cleaning efficiency. Ideal for handling stringy materials like vines or wire, this cleaner offers exceptional durability and easy maintenance. Maximize conveyor efficiency and reduce clean-up costs with the MARTIN® IN-LINE Chevron Belt Cleaner.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Belt Width
24 in | 500 to 650 mm
Dimensions Blade Width A
21 in | 533 mm
Dimensions Max Mainframe Length
54 in | 1372 mm
Dimensions Of Blades
3
Dimensions Shipping Weight
60 lb | 27.2 kg
Specifications Blade Type
Urethane
Specifications Blade Wear Life
2 in | 50 mm
Specifications Max Belt Speed
500 fpm | 2.50 m/s
Specifications Max Height
0.50 in | 13 mm
Specifications Max Service Constant Temperature
150 ºF | 65 ºC
Specifications Max Service Intermittent Temperature
180 ºF | 82 ºC
Specifications Mounting Radius
4 in | 102 mm
Specifications Recommended Tensioner
Reversing Mount Spring Tensioner
Specifications Urethane Color
Tan
