MARTIN® IN-LINE Chevron Belt Cleaner | Rubber Blades | 42-inch Width
MARTIN® IN-LINE Chevron Belt Cleaner | Rubber Blades | 42-inch Width
SKU:BEL-097e23
Enhance conveyor performance with MARTIN® IN-LINE Chevron Belt Cleaner - optimal for materials prone to tangling. Maximize efficiency now!
Regular price
$759.99
Regular price
Sale price
$759.99
Unit price
per
Initiate Order
MARTIN® IN-LINE Chevron Belt Cleaner | Rubber Blades | 42-inch Width
$759.99
Quantity: 1
Claim Your Seller Account
MARTIN® IN-LINE Chevron Belt Cleaner | Rubber Blades | 42-inch Width
$759.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MARTIN® IN-LINE Chevron Belt Cleaner is expertly designed with rubber blades to effectively eliminate carryback, particularly ideal for materials prone to catching like vines or wires. With 30º-offset arms, it navigates belts with ribs, chevrons, and cleats effortlessly. This cleaner boasts a durable construction, featuring a max belt speed of 500 fpm and temperature resistance up to 180ºF. Increase efficiency and reduce conveyor clean-up costs with the MARTIN® IN-LINE Chevron Belt Cleaner.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Belt Width
42 in | 1000 to 1200 mm
Dimensions Blade Width A
42 in | 1067 mm
Dimensions Max Mainframe Length
72 in | 1829 mm
Dimensions Of Blades
6
Dimensions Shipping Weight
85 lb | 38.60 kg
Specifications Blade Type
Ruber
Specifications Blade Wear Life
2 in | 50 mm
Specifications Max Belt Speed
500 fpm | 2.50 m/s
Specifications Max Height
0.50 in | 13 mm
Specifications Max Service Constant Temperature
150 ºF | 65 ºC
Specifications Max Service Intermittent Temperature
180 ºF | 82 ºC
Specifications Mounting Radius
4 in | 102 mm
Specifications Recommended Tensioner
Reversing Mount Spring Tensioner
