MARTIN® IN-LINE Chevron Belt Cleaner - Urethane Blades
MARTIN® IN-LINE Chevron Belt Cleaner - Urethane Blades
SKU:BEL-e7b5b6
Efficiently remove carryback with MARTIN® IN-LINE Chevron Belt Cleaner's urethane blades. Ideal for stringy materials. Tensioner sold separately.
Regular price
$899.99
Regular price
Sale price
$899.99
Unit price
per
Initiate Order
MARTIN® IN-LINE Chevron Belt Cleaner - Urethane Blades
$899.99
Quantity: 1
Claim Your Seller Account
MARTIN® IN-LINE Chevron Belt Cleaner - Urethane Blades
$899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MARTIN® IN-LINE Chevron Belt Cleaner features durable urethane blades that efficiently remove carryback while smoothly navigating belts with ribs, chevrons, and cleats. Designed with 30º-offset arms for optimal performance, this cleaner is ideal for handling stringy materials like vines, wire, or bark. With dimensions suitable for belt widths of 60 inches and a tensioner sold separately, it offers reliable belt cleaning to reduce maintenance costs and ensure conveyor efficiency.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Belt Width
60 in | 1600 to 1800 mm
Dimensions Blade Width A
56 in | 1422 mm
Dimensions Max Mainframe Length
102 in | 2591 mm
Dimensions Of Blades
8
Dimensions Shipping Weight
105 lb | 47.60 kg
Specifications Blade Type
Urethane
Specifications Blade Wear Life
2 in | 50 mm
Specifications Max Belt Speed
500 fpm | 2.50 m/s
Specifications Max Height
0.50 in | 13 mm
Specifications Max Service Constant Temperature
150 ºF | 65 ºC
Specifications Max Service Intermittent Temperature
180 ºF | 82 ºC
Specifications Mounting Radius
4 in | 102 mm
Specifications Recommended Tensioner
Reversing Mount Spring Tensioner
Specifications Urethane Color
Tan
