MARTIN® TORSION ARM™ Chevron Belt Cleaner - Conveyor Cleaning Solution

MARTIN® TORSION ARM™ Chevron Belt Cleaner - Conveyor Cleaning Solution

BEL-c32947

Efficiently remove carryback and reduce clean-up costs with the MARTIN® TORSION ARM™ Chevron Belt Cleaner. Perfect for industrial conveyor systems.

$599.99
$599.99
Sale

Initiate Order

MARTIN® TORSION ARM™ Chevron Belt Cleaner - Conveyor Cleaning Solution

MARTIN® TORSION ARM™ Chevron Belt Cleaner - Conveyor Cleaning Solution

$599.99

Quantity: 1

Claim Your Seller Account

MARTIN® TORSION ARM™ Chevron Belt Cleaner - Conveyor Cleaning Solution

MARTIN® TORSION ARM™ Chevron Belt Cleaner - Conveyor Cleaning Solution

$599.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The MARTIN® TORSION ARM™ Chevron Belt Cleaner is a top-tier conveyor cleaning solution from the MARTIN® Chevron Cleaners product line. Designed with precision, it features rubber or urethane blades that effectively eliminate carryback while smoothly maneuvering over belts with ribs, chevrons, and cleats. The 30° offset arms ensure efficient cleaning, especially in scenarios where materials like vines, wire, or bark may get entangled. This cleaner boasts telescoping ends for hassle-free installation, eliminating the need for mainframe cutting. With dimensions tailored for optimal performance and exceptional build quality, it's a must-have for reducing conveyor clean-up costs in industrial settings.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Dimensions Belt Width
18 in | 400 to 500 mm
Dimensions Blade Width A
12.5 in | 318 mm
Dimensions Max Mainframe Length
43 in | 1092 mm
Dimensions Of Blades
2
Dimensions Shipping Weight
55 lb | 24.9 kg
Specifications Arm Angle
Right
Specifications Blade Type
Urethane
Specifications Blade Wear Life
2 in | 50 mm
Specifications Max Belt Speed
500 fpm | 2.50 m/s
Specifications Max Height
0.50 in | 13 mm
Specifications Max Service Constant Temperature
150 ºF | 65 ºC
Specifications Max Service Intermittent Temperature
180 ºF | 82 ºC
Specifications Mounting Radius
4 in | 102 mm
Specifications Recommended Tensioner
MARTIN® TWIST™ Tensioner
Specifications Urethane Color
Green
