MPI™ MARSA Soft Seat Relief Valve - 1/2 x 3/4
MPI™ MARSA Soft Seat Relief Valve - 1/2 x 3/4
SKU:VAL-d4b28a
Dependable MPI™ MARSA Soft Seat Relief Valve for precise gas venting - ideal for pressure gas systems.
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Initiate Order
MPI™ MARSA Soft Seat Relief Valve - 1/2 x 3/4
$249.99
Quantity: 1
Claim Your Seller Account
MPI™ MARSA Soft Seat Relief Valve - 1/2 x 3/4
$249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MPI™ MARSA Soft Seat Relief Valve (Factory Set) offers reliable venting of gases at pressures ranging from 1,500 psi to 15,000 psi. This precision valve features a soft seat design for bubble-tight sealing, repeatable pop-off, and reseat capabilities. With a wide operating temperature range from -50ºF to 400ºF, it ensures dependable performance in various conditions. Not recommended for liquid nitrogen or liquid carbon dioxide applications, this valve is ideal for pressure gas systems demanding zero leakage. Its factory set pressure ensures accuracy, while meeting industry standards for durability and performance.
Product Specifications
Dimensions A
10.62 in
Dimensions Back Pressure Max
500 psi | 34 bar
Dimensions Connection
MPI™ to FNPT
Dimensions Orifice Diameter
.156 in
Dimensions Pressure Rating Max
15000 psi | 1035 bar
Dimensions Pressure Rating Min
10000 psi | 690 bar
Dimensions Repair Kits
R8MARSA-15K-2507
Dimensions Size
1/2 x 3/4
Specifications Caution
Parker Relief Valves are preset and factory sealed. Warranty is voided if seal is broken by customer. Maximum system operating pressure should not exceed 90% of relief valve set pressure. Pressures in excess of this value may cause weepage resulting in damage to plug and seat. Care should be taken when locating a relief valve within a piping system to keep the relief valve as far from the pump as possible. Certain pumps create an end-of-stroke spike in pressure that is not detectable by common instrumentation. These spikes could cause premature failure of the relief valve.
