MPI™ MARSA Soft Seat Relief Valve - Factory Set (1/2 x 3/4, 5000-10000 psi)
MPI™ MARSA Soft Seat Relief Valve - Factory Set (1/2 x 3/4, 5000-10000 psi)
SKU:VAL-5cfcd3
Engineered for precision gas systems, the MPI™ MARSA Relief Valve offers reliable venting from 1,500 to 15,000 psi, with bubble tight sealing and repeatable functionality.
Regular price
$239.99
Regular price
Sale price
$239.99
Unit price
per
Initiate Order
MPI™ MARSA Soft Seat Relief Valve - Factory Set (1/2 x 3/4, 5000-10000 psi)
$239.99
Quantity: 1
Claim Your Seller Account
MPI™ MARSA Soft Seat Relief Valve - Factory Set (1/2 x 3/4, 5000-10000 psi)
$239.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MPI™ MARSA Soft Seat Relief Valve (Factory Set) is engineered for precision gas systems, offering reliable venting from 1,500 psi to 15,000 psi. With a soft seat design ensuring bubble tight sealing and repeatable functionality, this valve provides unparalleled performance and longevity. Designed to withstand extreme temperatures (-50ºF to 400ºF), this valve meets the most stringent leakage requirements for critical applications, making it ideal for pressure gas systems. Ensure safety and efficiency with the MPI™ MARSA Soft Seat Relief Valve.
Product Specifications
Dimensions A
10.62 in
Dimensions Back Pressure Max
500 psi | 34 bar
Dimensions Connection
MPI™ to FNPT
Dimensions Orifice Diameter
.156 in
Dimensions Pressure Rating Max
10000 psi | 690 bar
Dimensions Pressure Rating Min
5000 psi | 345 bar
Dimensions Repair Kits
R8MARSA-10K
Dimensions Size
1/2 x 3/4
Specifications Caution
Parker Relief Valves are preset and factory sealed. Warranty is voided if seal is broken by customer. Maximum system operating pressure should not exceed 90% of relief valve set pressure. Pressures in excess of this value may cause weepage resulting in damage to plug and seat. Care should be taken when locating a relief valve within a piping system to keep the relief valve as far from the pump as possible. Certain pumps create an end-of-stroke spike in pressure that is not detectable by common instrumentation. These spikes could cause premature failure of the relief valve.
