NOMAD® 3" Aluminum Pwr-Flo™ AODD Pump with Neoprene Diaphragm
NOMAD® 3" Aluminum Pwr-Flo™ AODD Pump with Neoprene Diaphragm
SKU:MAN-2c0a5b
High-performance 3" Aluminum Pwr-Flo™ AODD Pump with Neoprene Diaphragm for efficient and reliable liquid transfer applications.
Regular price
$1,899.99
Regular price
Sale price
$1,899.99
Unit price
per
Initiate Order
NOMAD® 3" Aluminum Pwr-Flo™ AODD Pump with Neoprene Diaphragm
$1,899.99
Quantity: 1
Claim Your Seller Account
NOMAD® 3" Aluminum Pwr-Flo™ AODD Pump with Neoprene Diaphragm
$1,899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The NOMAD® 3" Aluminum Pwr-Flo™ AODD Pump with Neoprene Diaphragm is a high-performance industrial pump designed for both consumer and institutional needs. This pump features an efficient air system with an asymmetrical spool design for handling large solids and slurries. Its anti-stalling design ensures reliable performance in liquid transfer applications. Made of chemically resistant polypropylene, this pump is a drop-in replacement for Wilden® AODD pumps, providing excellent durability and longevity. With a 3" inlet and outlet size, this pump is ideal for filling, batching, and various industrial applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications 0
Drop in replacement for Wilden® AODD pumps of equivalent make and sizeAir driven double diaphragm pumps handle large solids and slurriesPWR-FLO⢠asymmetrical spool design (ASD) features an efficient air systemThe anti-stalling design also provides excellent reliability in on/off liquid transfer for filling and batching applicationsThe air valve and center section is made of chemically resistant polypropylene.
Specifications Check Valve Seat
Neoprene
Specifications Customs Code
Schedule B Code 8413.50.00.50
Specifications Diaphragm Material
Neoprene
Specifications Elastomers
Neoprene, Neoprene
Specifications Fluid Inlet Size
3 in | 76 mm
Specifications Fluid Outlet Size
3 Flanged ANSI in | 76 Flanged ANSI mm
Specifications Height
36 Inch | 36 in | 914.40 mm
Specifications Length
24 Inch | 24 in | 0.6096 m | 609.60 mm
Specifications Model
NPF80/AAAA/NE/NE/NE/FLA/B/X
Specifications Non Wetted Material
Aluminum
Specifications Similar Or Comparable To Brand
Nomad®
Specifications Similar Or Comparable To Part
80-1653
Specifications Wetted Moc
Aluminum
Specifications Width
24 Inch | 24 in | 0.6096 m | 609.60 mm
