Parker MARA Metal Seat Relief Valve (Factory Set) - MPI™ Specialty Valves
Parker MARA Metal Seat Relief Valve (Factory Set) - MPI™ Specialty Valves
SKU:VAL-e1816b
Reliable Parker MARA Metal Seat Relief Valve with precise pressure venting for diverse industrial applications.
Regular price
$359.99
Regular price
Sale price
$359.99
Unit price
per
Initiate Order
Parker MARA Metal Seat Relief Valve (Factory Set) - MPI™ Specialty Valves
$359.99
Quantity: 1
Claim Your Seller Account
Parker MARA Metal Seat Relief Valve (Factory Set) - MPI™ Specialty Valves
$359.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Parker MARA Series Metal Seat Relief Valve is a precision-engineered solution designed for venting gases or liquids at pressures ranging from 3,000 psi to 15,000 psi. With a standard temperature range of -423ºF to 400ºF, this valve is ideal for pressure gas systems, cryogenic applications, and petrochemical processes. Not only does it offer high reliability and accuracy, but it also features a high-temperature option up to 750ºF. Designed to handle air, gases, steam, and liquids, this valve is factory set and ensures consistent performance, making it suitable for various industrial uses.
Product Specifications
Dimensions A
10.62 in
Dimensions Back Pressure Max
500 psi | 34 bar
Dimensions Connection
MPI™ to FNPT
Dimensions Orifice Diameter
.188 in
Dimensions Pressure Rating Max
15000 psi | 1035 bar
Dimensions Pressure Rating Min
10000 psi | 690 bar
Dimensions Repair Kits
R9MARA-15K-2507
Dimensions Size
9/16 x 3/4
Specifications Caution
Parker Relief Valves are preset and factory sealed. Warranty is voided if seal is broken by customer. Maximum system operating pressure should not exceed 90% of relief valve set pressure. Pressures in excess of this value may cause weepage resulting in damage to plug and seat.Care should be taken when locating a relief valve within a piping system to keep the relief valve as far from the pump as possible. Certain pumps create an end-of-stroke spike in pressure that is not detectable by common instrumentation. These spikes could cause premature failure of the relief valve.
