Petersen® 161-5 Series High Pressure Heavy Duty Bag - 20x20 in
Petersen® 161-5 Series High Pressure Heavy Duty Bag - 20x20 in
SKU:HIG-45b7e4
Enhanced lift capacity & durability in Petersen® 161-5 Series HP Heavy Duty Bag - 20x20 in. Perfect for heavy lifting with 25% higher inflation pressure & safety features.
Regular price
$189.99
Regular price
Sale price
$189.99
Unit price
per
Initiate Order
Petersen® 161-5 Series High Pressure Heavy Duty Bag - 20x20 in
$189.99
Quantity: 1
Claim Your Seller Account
Petersen® 161-5 Series High Pressure Heavy Duty Bag - 20x20 in
$189.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Petersen® 161-5 Series High Pressure Heavy Duty Bag in 20x20 in size offers unmatched lift capacity with 25% higher inflation pressure at 145 psi, ensuring efficient heavy lifting operations. Its lightweight yet durable design features a special rib surface for secure stacking, with a safety factor of 4 and burst pressure exceeding 580 psi. Made of Aramid reinforced rubber compound, this bag is compatible with conventional 116 PSI control systems, suitable for -40 to 130 ºF operations.
Product Specifications
Specifications A Width
1.5 in | 38.10 mm
Specifications Block Thickness
0.62 in | 15.75 mm
Specifications B Length
0.75 in | 19.05 mm
Specifications Connection Type
W125
Specifications C Length
0.31 in | 7.87 mm
Specifications D1 Height
0.81 in | 20.57 mm
Specifications D Height
1.06 in | 26.92 mm
Specifications E Height
1.38 in | 35.05 mm
Specifications F Length
3.00 in | 76.20 mm
Specifications G1 Bracket Mounting Hole Size
0.17 in | 4.32 mm
Specifications G Packing Gland Mounting Hole Drill Size
0.62 in | 15.75 mm
Specifications H Height
3.75 in | 95.25 mm
Specifications M Length
0.56 in | 14.22 mm
Specifications N Height
0.31 in | 7.87 mm
Specifications Orifice Diameter
0.094 in | 2.39 mm
Specifications Outside Diameter Tube
1/8 in | 3.18 mm
Specifications Pressure Rating At Room Temperature
15000 psi | 1034 bar
Specifications Rated Cv
0.12
Specifications Stem Type
VEE
Specifications Tubing Engagement Depth
0.47 in | 11.9 mm
Specifications Valve Pattern
2-Way Straight
Valve Maintenance Valve Maintenance
Repair Kits:add "R" to the front of valve catalog number for proper repair kit. (Example: R10V4071)Valve Bodies:Valve bodies are available. Order using the eight (8) digit part number found on the valve drawing or contact your Sales Representative for information.Consult your Autoclave representative for pricing on repair kits and valve bodies. Refer to the Tools, Installation, Operation and Maintenance section for proper maintenance procedures.
Valve Options Valve Options
Extreme TemperaturesStandard Autoclave valves with Teflon packing may be operated to 450°F (232°C). High temperature packing and/or extended stuffing box is available for service from 0°F (-17.8°C) to 650°F (343°C) by adding the following suffixes to catalog order number.â TG standard valve with Teflon glass packing to 600°F (316°C).GY standard valve with graphite braided yarn packing to 650°F (343°C).â Autoclave Engineers does not recommend compression sleeve connections below 0°F (-17.8°C) or above 650°F (343°C). For additional valve options, contact your Sales Representative.
