San Ace 92 Series AC Fan with Sensor
San Ace 92 Series AC Fan with Sensor
Reliable San Ace 92 AC Fan with Sensor for industrial cooling needs. Durable, efficient, and compliant with safety standards.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
San Ace 92 Series AC Fan with Sensor
$49.99
Quantity: 1
Claim Your Seller Account
San Ace 92 Series AC Fan with Sensor
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 109S496 San Ace 92 Series AC Fan with Sensor is a reliable cooling solution perfect for industrial and institutional applications. With a durable aluminum frame and UL94V-1 rated plastic impeller, this fan ensures safety and longevity. It boasts a dielectric strength of up to 1,500VAC, meeting stringent quality standards. Operating flawlessly in temperatures ranging from -10 to +60 ºC, this fan delivers a rated speed of 1500/1700 RPM, providing maximum air flow of 0.55/0.65 m³/min. Trust in its 25,000-hour expected life and quiet operation at 24/27 dBA, making it ideal for various settings.
Product Specifications
Specifications Current
0.09/0.08 A
Specifications Dielectric Strength
50/60Hz 1,500VAC 1minute (between input terminal and frame)
Specifications Dielectric Strength With Sensor Between Ac Input
50/60 Hz 1,500 VAC 1 minute
Specifications Dielectric Strength With Sensor Between G And Dc
50/60Hz 1,000VAC 1minute
Specifications Dimensions
92Ã92Ã25 mm
Specifications Expected Life At 60c
25000 hours
Specifications Frame Material
Aluminum
Specifications Frequency
50/60 Hz
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Input
7/6 W
Specifications Locked Rotor Current
0.09/0.08 A
Specifications Mass
310 g
Specifications Maximum Air Flow
0.55/0.65 m³/min | 19.4/23 ft³/min
Specifications Maximum Static Pressure
12.5/16.3 Pa | 0.050/0.065 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature
-10 to +60 ºC
Specifications Operating Voltage Range
Voltage of each model ±10%
Specifications Rated Speed
1500/1700
Specifications Rated Voltage
100 V
Specifications Sensor Purpose Anode Lead Wire Color
Brown
Specifications Sensor Purpose Cathode Lead Wire Color
Black
Specifications Sensor Purpose Lead Wire Color
Yellow
Specifications Sound Pressure Level
24/27 dBA
