SpanTech® 50mm PillowTop Link Chain with 6mm Moving Side Guide - Right Hand, Blue

SpanTech® 50mm PillowTop Link Chain with 6mm Moving Side Guide - Right Hand, Blue

SKU:CHA-32c52c

Upgrade to the SpanTech® 50mm PillowTop Chain for precise and sanitary conveyance of delicate products.

Regular price $129.99
Regular price Sale price $129.99
Sale

Initiate Order

SpanTech® 50mm PillowTop Link Chain with 6mm Moving Side Guide - Right Hand, Blue

SpanTech® 50mm PillowTop Link Chain with 6mm Moving Side Guide - Right Hand, Blue

$129.99

Quantity: 1

Claim Your Seller Account

SpanTech® 50mm PillowTop Link Chain with 6mm Moving Side Guide - Right Hand, Blue

SpanTech® 50mm PillowTop Link Chain with 6mm Moving Side Guide - Right Hand, Blue

$129.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The SpanTech® 50mm PillowTop Link Chain with a 6mm Moving Side Guide in Right Hand orientation and Blue color is a game-changer in conveyor systems. Designed with a tight turning radius and lightweight yet durable Acetal material, this chain offers superior performance for delicate product handling. Its sanitary open design enhances cleanability, making it ideal for food industries. The unique curved design minimizes chordal action, allowing precise positioning for seamless transfers. Replace your 50mm SuperTight chain with ease and upgrade to the efficiency and reliability of the SpanTech® PillowTop Link Chain.

Product Specifications

Additional Information Additional Information
Handles the most delicate of products with ease and precision.
Chain Options Chain Options
Plain (White or Blue)Moving Side Guide (White or Blue)
Specifications Available Width Ranges
3.76 to 46.28 in | 95.6 to 1205.6 mm
Specifications Color
Blue
Specifications Durable
50 mm PillowTop Chain is very lightweight yet very strong.
Specifications Material Options
Acetal
Specifications Moving Direction
Right Hand
Specifications Moving Side Guide Size
6 mm
Specifications Pitch Size
1.97 in | 50 mm
Specifications Sanitary
The open design concept improves cleanability and makes it perfect for cooling applications.
Specifications Tight Turning Radius
50 mm PillowTop chain has one of the tighter turning radii that Span Tech offers.
What Is Chordal Action What Is Chordal Action
The rising and lowering of an individual chain link as it enters a sprocket is known as chordal action. The reason it happens is simply due to geometry. When a chain is "wrapped" around a sprocket, the pins of the chain form a polygon shape. When you look at this polygon shape traveling around a sprocket, it is bumpy - not smooth. When a conveyor chain enters a drive sprocket, it goes from a flat line to this polygon shape and results in a rise/lowering of the pin. This effect can be lessened only by using a smaller pitch chain, or increasing the sprocket size - it cannot be prevented. That being said, depending on the elevation of the chain (in relation to the sprocket), we can control whether the chain "rises" or "lowers" to match this polygon shape.
