Torlon® 4203 PAI Round Bar
Torlon® 4203 PAI Round Bar
SKU:SHA-4c18c4
High-strength Torlon® 4203 PAI Round Bar, ideal for extreme conditions with temperature stability up to 500ºF. Perfect for industrial applications.
Regular price
$25.99
Regular price
Sale price
$25.99
Unit price
per
Initiate Order
Torlon® 4203 PAI Round Bar
$25.99
Quantity: 1
Claim Your Seller Account
Torlon® 4203 PAI Round Bar
$25.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Torlon® 4203 PAI Round Bar is a high-performance engineering plastic known for its exceptional strength, stiffness, and resistance to extreme conditions. With a specific gravity of 1.41, this bar boasts a tensile strength of 20,000 psi and a flexural strength of 23,900 psi. It is tailored for applications requiring stability at temperatures up to 500ºF, making it ideal for high-temperature electrical connectors, chip nests & sockets, and mandrels. Torlon® 4203 PAI ensures reliability in challenging thermal, chemical, and stress environments, making it a top choice for critical industrial needs.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Applications
High temperature electrical connectors.Chip nests & sockets.Can mandrel
Characteristics Characteristics
Maintains strength & stiffness to 500ºF.Minimal expansion rate to 500ºF.Able to endure harsh thermal, chemical and stress conditions.
Specifications Availability
stock
Specifications Coefficient Of Friction Static
0.35
Specifications Color
Brown/Yellow
Specifications Compressive Modulus
479000 psi
Specifications Compressive Strength
23900 psi
Specifications Dielectric Strength
580 V/mil
Specifications Flammability At 125 Ul94
V0
Specifications Flexural Modulus
600000 psi
Specifications Flexural Strength
23900 psi
Specifications Glass Transition Temperature
527 ºF
Specifications Hardness Rockwell
E80 / M120
Specifications Heat Deflection Temperature 264 Psi
532 ºF
Specifications Izod Impact Strength Notched Astm D256
2.0
Specifications Material
PAI
Specifications Minimum Order
1
Specifications Optional Lengths
1', 4'
Specifications Specific Gravity
1.41
Specifications Standard Length
8' ft
Specifications Tensile Elongation Break
10%
Specifications Tensile Modulus
600000 psi
Specifications Tensile Strength
20000 psi
Specifications Tolerance
+only in
Specifications Water Absorption 24 Hrs
0.40 %
Specifications Water Absorption Saturation Astm D570
1.70
