Torlon® 4203 Polyamide-imide Round Bar

Torlon® 4203 Polyamide-imide Round Bar

SHA-d05814

High-performance Torlon® 4203 Round Bar - Strong, durable, and heat-resistant for demanding applications. Buy now!

$45.99
$45.99
Sale

Initiate Order

Torlon® 4203 Polyamide-imide Round Bar

Torlon® 4203 Polyamide-imide Round Bar

$45.99

Quantity: 1

Claim Your Seller Account

Torlon® 4203 Polyamide-imide Round Bar

Torlon® 4203 Polyamide-imide Round Bar

$45.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
Experience exceptional performance with the Torlon® 4203 Polyamide-imide Round Bar. Crafted from high-quality PAI material in brown/yellow, this bar offers remarkable tensile and flexural strength, with a heat deflection temperature of 532 ºF. Ideal for high temperature electrical connectors and chip nests, it endures harsh conditions effortlessly.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Applications Applications
High temperature electrical connectors.Chip nests & sockets.Can mandrel
Characteristics Characteristics
Maintains strength & stiffness to 500ºF.Minimal expansion rate to 500ºF.Able to endure harsh thermal, chemical and stress conditions.
Specifications Availability
stock
Specifications Coefficient Of Friction Static
0.35
Specifications Color
Brown/Yellow
Specifications Compressive Modulus
479000 psi
Specifications Compressive Strength
23900 psi
Specifications Dielectric Strength
580 V/mil
Specifications Flammability At 125 Ul94
V0
Specifications Flexural Modulus
600000 psi
Specifications Flexural Strength
23900 psi
Specifications Glass Transition Temperature
527 ºF
Specifications Hardness Rockwell
E80 / M120
Specifications Heat Deflection Temperature 264 Psi
532 ºF
Specifications Izod Impact Strength Notched Astm D256
2.0
Specifications Material
PAI
Specifications Minimum Order
1
Specifications Optional Lengths
1'
Specifications Specific Gravity
1.41
Specifications Standard Length
4' ft
Specifications Tensile Elongation Break
10%
Specifications Tensile Modulus
600000 psi
Specifications Tensile Strength
20000 psi
Specifications Tolerance
+only in
Specifications Water Absorption 24 Hrs
0.40 %
Specifications Water Absorption Saturation Astm D570
1.70
