Torlon® 4203 Polyamide-imide Round Bar
Torlon® 4203 Polyamide-imide Round Bar
SKU:SHA-5368c8
High-performing Torlon® 4203 Polyamide-imide Round Bar suitable for extreme conditions and high temperatures. Ideal for electrical connectors and chip nests.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Torlon® 4203 Polyamide-imide Round Bar
$45.99
Quantity: 1
Claim Your Seller Account
Torlon® 4203 Polyamide-imide Round Bar
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Torlon® 4203 Polyamide-imide Round Bar is a high-performance material designed for demanding applications. With a specific gravity of 1.41 and exceptional strength properties including a tensile strength of 20,000 psi, this round bar is ideal for high temperature electrical connectors, chip nests & sockets, and can mandrels. Engineered to withstand extreme thermal, chemical, and stress conditions, it offers a heat deflection temperature of 532 ºF and a glass transition temperature of 527 ºF. Experience minimal expansion and excellent dimensional stability up to 500ºF, making it a reliable choice for critical applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Applications
High temperature electrical connectors.Chip nests & sockets.Can mandrel
Characteristics Characteristics
Maintains strength & stiffness to 500ºF.Minimal expansion rate to 500ºF.Able to endure harsh thermal, chemical and stress conditions.
Specifications Availability
stock
Specifications Coefficient Of Friction Static
0.35
Specifications Color
Brown/Yellow
Specifications Compressive Modulus
479000 psi
Specifications Compressive Strength
23900 psi
Specifications Dielectric Strength
580 V/mil
Specifications Flammability At 125 Ul94
V0
Specifications Flexural Modulus
600000 psi
Specifications Flexural Strength
23900 psi
Specifications Glass Transition Temperature
527 ºF
Specifications Hardness Rockwell
E80 / M120
Specifications Heat Deflection Temperature 264 Psi
532 ºF
Specifications Izod Impact Strength Notched Astm D256
2.0
Specifications Material
PAI
Specifications Minimum Order
1
Specifications Specific Gravity
1.41
Specifications Standard Length
8' ft
Specifications Tensile Elongation Break
10%
Specifications Tensile Modulus
600000 psi
Specifications Tensile Strength
20000 psi
Specifications Tolerance
+only in
Specifications Water Absorption 24 Hrs
0.40 %
Specifications Water Absorption Saturation Astm D570
1.70
