0.02mm Iron Boron Silicon Wire
0.02mm Iron Boron Silicon Wire
SKU:IRO-a45307
High-performance 0.02mm Iron/Boron/Silicon Wire for magnetic applications and more.
Regular price
$35.99
Regular price
Sale price
$35.99
Unit price
per
Initiate Order
0.02mm Iron Boron Silicon Wire
$35.99
Quantity: 1
Claim Your Seller Account
0.02mm Iron Boron Silicon Wire
$35.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 0.02mm Iron/Boron/Silicon Wire is a flexible strand designed with Fe77.5/B15/Si7.5 alloy, offering high tensile strength and electrical resistivity of 124 µΩ·cm. With a Grade of Metallic Glass, this wire provides exceptional performance in soft magnetic applications, brazing, and more. Its thermal properties include a Crystallization Temperature of 553ºC, making it a versatile choice for various industrial uses.
Product Specifications
Electrical Properties Electrical Resistivity
124 µΩ·cm
Magnetic Properties Curie Temperature
422 ºC
Material Material
Iron/Boron/SiliconMetallic glasses (glassy alloys) or amorphous metals. Uses include soft magnetic applications, brazing, coating and as reinforcing fibers.
Mechanical Properties Elongation At Break
2.3 %
Mechanical Properties Hardness Vickers
940 Kgf mm-2
Mechanical Properties Tensile Modulus
155.00 GPa
Specifications Diameter
0.02 mm
Specifications Form
Wire
Specifications Grade
Metallic Glass
Specifications Length
1 to 50 m
Specifications Tolerance For Length Round
-1 mm | +5 mm
Thermal Properties Coefficient Of Thermal Expansion At 20 Degree
8.700 x10-6 K-1
Thermal Properties Crystallization Temperature
553 ºC
Tolerances Disc Diameter Tolerance
10 %
Type Type
GlassGoodfellow offers two distinct types of glass products: The first are generally silica-based, non-crystalline (amorphous) solids which exhibit a glass transition and are brittle and transparent. The properties of glass materials can be readily modified to alter their optical performance and other characteristics. This type is available through Goodfellow's Ceramic and Glass Division. Generally, these products are made to order for customers, so we do not list them in our Catalog. Please contact us with your requirements. The second type of glass product is commonly referred to as "metallic glasses" or "glassy metals". In contrast to crystalline metals and alloys with highly ordered atomic structures, these are non-crystalline (amorphous) metals or, more usually, alloys. Our website details those glassy metals which are available from stock; please contact us if you are unable to find the item you specifically require.
