SKU:ALU-614c31
High-quality 0.05mm Al/Si Wire with 310.00 MPa tensile strength & 2.6-3.5 µΩ·cm electrical resistivity. Compliant with industry standards.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
0.05mm Al/Si Alloy Wire - Goodfellow Corp.
$29.99
Quantity: 1
Claim Your Seller Account
0.05mm Al/Si Alloy Wire - Goodfellow Corp.
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 0.05mm diameter Aluminum/Silicon (Al99/Si 1) Wire by Goodfellow Corp. is a high-quality, hard-temper wire suitable for various applications. With a tensile strength of 310.00 MPa and excellent electrical resistivity of 2.6 to 3.5 µΩ·cm, this wire guarantees reliable performance. Its density of 2.700 g·cm-3 and melting point of 600.00 ºC make it durable and ideal for demanding environments. Compliant with industry standards, this wire is a top choice for government and institutional procurement needs.
Product Specifications
Electrical Properties Electrical Resistivity
2.6 to 3.5 µΩ·cm
Electrical Properties Temperature Coefficient
0.00420 k-1
Material Material
Aluminum/SiliconAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities).Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Mechanical Properties Tensile Strength
310.00 MPa
Physical Properties Density
2.700 g·cm-3
Specifications Diameter
0.05 mm
Specifications Form
Wire
Specifications Length
5 to 100 m
Specifications Temper
Hard
Thermal Properties Melting Point
600.00 ºC
Tolerances Diameter Tolerance
10 %
Tolerances Length Round Tolerance
-1 % | +5 %
Type Type
AlloyAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities). Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Analysis Copper Cu
30 ppm
Analysis Iron Fe
60 ppm
Analysis Manganese Mn
30 ppm
