0.25mm Aluminum/Magnesium/Silicon Alloy Wire
0.25mm Aluminum/Magnesium/Silicon Alloy Wire
SKU:ALU-1fec0a
High-quality 0.25mm Aluminum/Magnesium/Silicon Alloy Wire for versatile applications. Excellent strength and conductivity.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
0.25mm Aluminum/Magnesium/Silicon Alloy Wire
$45.99
Quantity: 1
Claim Your Seller Account
0.25mm Aluminum/Magnesium/Silicon Alloy Wire
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 0.25mm Aluminum/Magnesium/Silicon Alloy Wire offered by Goodfellow Corp. is a flexible and durable wire suitable for various applications. With a diameter of 0.25mm and lengths ranging from 5 to 100 meters, this wire boasts excellent mechanical and thermal properties. It features a high tensile strength of 150.00 to 430.00 MPa, making it ideal for demanding industrial environments. Additionally, its electrical resistivity range of 3.4 to 3.8 µΩ·cm ensures efficient electrical conductivity. Compliant with industry standards, this wire is a reliable choice for both consumer and institutional buyers.
Product Specifications
Electrical Properties Electrical Resistivity
3.4 to 3.8 µΩ·cm
Electrical Properties Temperature Coefficient
0.00300 k-1
Material Material
Aluminum/Magnesium/SiliconAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities).Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Mechanical Properties Elongation At Break
< 20.0 %
Mechanical Properties Hardness Brinell
10 to 100
Mechanical Properties Izod Impact Strength
27.0 to 34.0 J m-1
Mechanical Properties Modulus Of Elasticity
70.0 GPa
Mechanical Properties Shear Strength
160 to 200 MPa
Mechanical Properties Tensile Strength
150.00 to 430.00 MPa
Physical Properties Density
2.690 g·cm-3
Specifications Diameter
0.25 mm
Specifications Form
Wire
Specifications Length
5 to 100 m
Specifications Temper
As Drawn
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
23.000 x10-6 K-1
Thermal Properties Specific Heat At 23 Degree Celsius C Temperat
904.0 J K-1 kg-1
Thermal Properties Thermal Conductivity At 23 Degree Celsius C T
180.00 to 193.00 W m-1K-1
Tolerances Diameter Tolerance
10 %
Tolerances Length Round Tolerance
-1 % | +5 %
Type Type
AlloyAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities). Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Analysis Chromium Cr
2500 ppm
Analysis Copper Cu
2500 ppm
Analysis Manganese Mn
1 %
Analysis Silicon Si
6000 ppm
