0.25mm Aluminum/Magnesium/Silicon Alloy Wire
0.25mm Aluminum/Magnesium/Silicon Alloy Wire
SKU:ALU-477acc
Versatile 0.25mm Aluminum/Magnesium/Silicon Alloy Wire for electrical and mechanical applications. High tensile strength and thermal conductivity.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
0.25mm Aluminum/Magnesium/Silicon Alloy Wire
$29.99
Quantity: 1
Claim Your Seller Account
0.25mm Aluminum/Magnesium/Silicon Alloy Wire
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 0.25mm Aluminum/Magnesium/Silicon (Al99/Mg 0.5/Si 0.5) Wire is a versatile solution for electrical and mechanical applications. With a diameter of 0.25mm and a length range of 1 to 50m, this wire offers high tensile strength ranging from 90.00 to 300.00 MPa and a modulus of elasticity of 69.5 GPa. Its thermal properties include a low coefficient of thermal expansion and a high thermal conductivity of 209.00 W m-1K-1, making it ideal for various temperature conditions. Compliant with industry standards, this wire is well-suited for both consumer and institutional buyers seeking reliable performance and durability.
Product Specifications
Electrical Properties Electrical Resistivity
3.2 µΩ·cm
Material Material
Aluminum/Magnesium/SiliconAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities).Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Mechanical Properties Elongation At Break
< 16.0 %
Mechanical Properties Modulus Of Elasticity
69.5 GPa
Mechanical Properties Tensile Strength
90.00 to 300.00 MPa
Physical Properties Density
2.700 g·cm-3
Specifications Diameter
0.25 mm
Specifications Form
Wire
Specifications Length
1 to 50 m
Specifications Temper
As Drawn
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
23.400 x10-6 K-1
Thermal Properties Melting Point
655.00 ºC
Thermal Properties Specific Heat At 23 Degree Celsius C Temperat
960.0 J K-1 kg-1
Thermal Properties Thermal Conductivity At 23 Degree Celsius C T
209.00 W m-1K-1
Tolerances Diameter Tolerance
10 %
Tolerances Length Round Tolerance
-1 % | +5 %
Type Type
AlloyAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities). Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
