0.375 inch Nickel 200 Alloy Plate
0.375 inch Nickel 200 Alloy Plate
SKU:NIC-ae28a9
Commercially pure wrought nickel plate with excellent corrosion resistance and mechanical properties for diverse applications.
Regular price
$65.99
Regular price
Sale price
$65.99
Unit price
per
Initiate Order
0.375 inch Nickel 200 Alloy Plate
$65.99
Quantity: 1
Claim Your Seller Account
0.375 inch Nickel 200 Alloy Plate
$65.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 0.375 inch Nickel 200 Alloy Plate is a commercially pure wrought nickel with exceptional mechanical properties and outstanding resistance to corrosion, making it ideal for a wide range of applications. With a high nickel content and low carbon composition, it offers excellent durability and reliability, especially in demanding environments such as food processing, chemical handling, aerospace, and more. This plate is designed to meet stringent institutional procurement standards and is a reliable choice for industries requiring superior corrosion resistance and mechanical strength.
Product Specifications
Additional Information Additional Information
Outstanding resistance to caustic alkalis up to and including the molten state. In acid, alkaline and neutral salt solutions the material shows good resistance, but in oxidizing salt solutions severe attack will occur. Resistant to all dry gases at room temperature and in dry chlorine and hydrogen chloride may be used in temperatures up to 550 ºC. Resistance to mineral acids varies according to temperature and concentration and whether the solution is aerated or not. Corrosion resistance is better in de-aerated acid.
Applications 0
Manufacture and handling of sodium hydroxide, particularly at temperature above 300 ºC.Production of viscose rayon. Manufacture of soap.Aniline hydrochloride production and in the chlorination of aliphatic hydrocarbons such as benzene, methane and ethane.Manufacture of vinyl chloride monomer.Storage and distribution systems for phenol immunity from any for of attack ensures absolute product purity.Reactors and vessels in which fluorine is generated and reacted with hydrocarbons
General Resistance Barrod Usa
B160
General Resistance Barrod Wkstf
17752
General Resistance Fitting Usa
B163
General Resistance Forging Usa
B564
General Resistance General Resistance
Corrosion
General Resistance Pipetube Usa
B161
General Resistance Pipetube Wkstf
17740
General Resistance Sheetplate Usa
B162
General Resistance Sheetplate Wkstf
17750
General Resistance Unified Numbering System Uns
N02200
General Resistance Weld Electrode
ENi-1
General Resistance Weld Wire
ERNi-Cl
General Resistance Werkstof
2.4066
Machinability Ratings Note
These machinability ratios must be recognized as approximate values. They are a reasonable guide to relative tool life and lower required for cutting. It is obvious, however, that variables of speed, cutting oil, feed and depth of cut will significantly affect these ratios.
Machinability Ratings Speed Percent Of B1112
40
Machinability Ratings Speed Surface
65 ft/mm
Machining Section 0
The alloys described here work harden rapidly during machining and require more power to cut than do the plain carbon steels. The metal is 'gummy', with chips that tend to be stringy and tough. Machine tools should be rigid and used to no more than 75% of their rated capacity. Both work piece and tool should be held rigidly; tool overhang should be minimized. Rigidity is particularly important when machining titanium, as titanium has a much lower modulus of elasticity than either steel or nickel alloys. Slender work pieces of titanium tend to deflect under tool pressures causing chatter, tool rubbing and tolerance problems.Make sure that tools are always sharp. Change to sharpened tools at regular intervals rather than out of necessity. Titanium chips in particular tend to gall and weld to the tool cutting edges, speeding up tool wear and failure. Remember- cutting edges, particularly throw-away inserts, are expendable. Don't trade dollars in machine time for pennies in tool cost.Feed rate should be high enough to ensure that the tool cutting edge is getting under the previous cut thus avoiding work-hardened zones. Slow speeds are generally required with heavy cuts. Sulfur chlorinated petroleum oil lubricants are suggested for all alloys but titanium. Such lubricants may be thinned with paraffin oil for finish cuts at higher speeds. The tool should not ride on the work piece as this will work harden the material and result in early tool dulling or breakage. Use an air jet directed on the tool when dry cutting, to significantly increase tool life.Lubricants or cutting fluids for titanium should be carefully selected. Do not use fluids containing chlorine or other halogens (fluorine, bromine or iodine), in order to avoid risk of corrosion problems. The speeds are for single point turning operations using high speed steel tools. This information is provided as a guide to relative machinability, higher speeds are used with carbide tooling.
Mechanical Elongation
35 to 10 %
Mechanical Hardness
B75 - 98
Mechanical Mechanical Type
Cold Drawn
Mechanical Tensile Strength
65 to 110 ksi
Mechanical Yield Strength
40 to 100 ksi
Nominal Chemistry Maximum Carbon C
0.08
Nominal Chemistry Maximum Copper Cu
0.25
Nominal Chemistry Maximum Iron Fe
0.4
Nominal Chemistry Maximum Manganese Mn
0.35
Nominal Chemistry Maximum Silicon Si
0.35
Nominal Chemistry Minimum Nickel Ni
99.0
Nominal Chemistry Other
S 0.01 max
Physical Curie Temperature
680 ºF
Physical Density
0.321 lb/in³
Physical Melting Range
2615 to 2635 ºF
Physical Specific Heat
0.109 Btu/lb ºF
Physical Thermal Expansion Coefficient At 70 To 200 Degree Fahre
4.7 x 10-6 in/in/ºF
Specifications Alloy
200
Specifications Size
0.375 in
Specifications Type
Plate
