0.4mm Aluminum Silicon Alloy Wire
0.4mm Aluminum Silicon Alloy Wire
SKU:ALU-5e4b5e
High-quality 0.4mm Aluminum Silicon Alloy Wire with excellent conductivity and strength. Ideal for various applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
0.4mm Aluminum Silicon Alloy Wire
$29.99
Quantity: 1
Claim Your Seller Account
0.4mm Aluminum Silicon Alloy Wire
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 0.4mm Aluminum Silicon (Al88/Si12) Wire by Goodfellow Corp. is a high-quality, flexible wire with a diameter of 0.4mm and lengths ranging from 0.5m to 10m. With excellent electrical conductivity and thermal properties, this wire is ideal for various applications. It boasts a tensile strength of 241.50 MPa and a modulus of elasticity of 71.1 GPa, meeting rigorous industry standards.
Product Specifications
Electrical Properties Electrical Resistivity
5.56 µΩ·cm
Material Material
Aluminum/SiliconAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities).Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Mechanical Properties Elongation At Break
< 20.0 %
Mechanical Properties Modulus Of Elasticity
71.1 GPa
Mechanical Properties Tensile Strength
241.50 MPa
Physical Properties Density
2.660 g·cm-3
Specifications Diameter
0.4 mm
Specifications Form
Wire
Specifications Length
0.5 to 10 m
Specifications Temper
As Drawn
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
20.400 x10-6 K-1
Thermal Properties Melting Point
577.00 ºC
Thermal Properties Thermal Conductivity At 23 Degree Celsius C T
121.00 W m-1K-1
Tolerances Diameter Tolerance
10 %
Tolerances Length Round Tolerance
-1 % | +5 %
Type Type
AlloyAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities). Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
