04A Flat Board Side x .187 Chassis Hole Circuit Board Support
04A Flat Board Side x .187 Chassis Hole Circuit Board Support
SKU:01C-29750d
Versatile circuit board support for densely loaded PC boards, easy to install without tools or screws. RoHS compliant, UL listed, and meets ASTM standards.
Regular price
$12.99
Regular price
Sale price
$12.99
Unit price
per
Initiate Order
04A Flat Board Side x .187 Chassis Hole Circuit Board Support
$12.99
Quantity: 1
Claim Your Seller Account
04A Flat Board Side x .187 Chassis Hole Circuit Board Support
$12.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Designed for easy installation without the need for tools or screws, the 04A Flat Board Side x .187 Chassis Hole Circuit Board Support is a versatile solution for supporting densely loaded PC boards. Made of Nylon 66 UL94V-2 material (UL94V-0 available), this support is UL listed (File No: E70062) and meets ASTM standards. With a panel range of 040-.078 inches, this support is RoHS compliant and can withstand temperatures ranging from -40 to 185F (-40 to 85C). Ensure secure mounting with the .187-inch mounting hole diameter. Enhance your circuit board assembly with this reliable and durable support solution.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Chassis Thickness
040-.078 (1-1.9) inches (mm)
Specifications Color
Natural
Specifications Dim L
.875 (22.2) inches (mm)
Specifications Mounting Hole Diameter
.187 (4.8) inches (mm)
