1.015 in Silicon Carbide Abrasive Nylon Twisted Brush, 500 Grit
1.015 in Silicon Carbide Abrasive Nylon Twisted Brush, 500 Grit
SKU:TWI-f28dc7
Optimize deburring with the 1.015 in 500 Grit Silicon Carbide Nylon Twisted Brush!
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
1.015 in Silicon Carbide Abrasive Nylon Twisted Brush, 500 Grit
$29.99
Quantity: 1
Claim Your Seller Account
1.015 in Silicon Carbide Abrasive Nylon Twisted Brush, 500 Grit
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 1.015 Inch Silicon Carbide Abrasive Nylon Twisted Brush is meticulously engineered for ultra-fine deburring in small diameter holes without compromising dimensions or surface finishes. Designed for precision, this brush features a single stem, single spiral construction with a continuous end that ensures optimal performance. Ideal for power tool usage with a recommended operating speed of 100-500 RPM, this brush guarantees efficiency and safety. Encounter unparalleled cleaning and deburring capabilities with this premium Tanis® brush.
Product Specifications
Before Starting The Twist Brush Rotation
Secure the brush in the chuck.Ensure clockwise brush rotation-counter clockwise rotation can cause the brush to come apart and release the filament.Securely clamp the workpiece. Make sure all machine guards are in position.Align the brush with the workpiece to ensure the brush rotates on its true center line and avoid stem deflection.Guide the brush into the hole before starting the brush rotation.Always wear eye protection and protective clothing!
Note
Other sizes are available upon request.
Operating Recommendations
When mounting a twisted brush in a collet or chuck, it is recommended to minimize the overhang of the stem to under an inch. This is particularly true with power tube brushes, and it is important to avoid any load conditions and operating speeds that can cause stem deflections and destructive bending. A safe operating speed from 100-500 RPM is recommended for most twisted brushes.To reach into deeper holes we recommend the use of collet-ready shank mounted brushes or drill extension rods rather than increasing stem overhang.
Other Considerations
Wire OptionsCoatedGalvanizedStainless SteelFilament OptionsAbrasive NylonCeramiX®BrassCarbon SteelHorse HairNylonStainless SteelCrimped, Level or Color OptionsGaugeStem DiameterOtherShank TypeTubingCouplingLoopNo Loop
Specifications Brush Diameter
1.015 in
Specifications Brush Length
1 in
Specifications Brush Tip Styles
Continuous End | Cut Off End
Specifications Filament Diameter
0.022 in
Specifications Hole Diameter Decimal
1 in | 25.40 mm
Specifications Hole Diameter Fractional
1 in
Specifications Material
Silicon Carbide
Specifications Overall Length
5 in
Specifications Size
500 grit
Specifications Stem Diameter
0.248 in
Twisted Brush Stem Construction
Single stem, single spiral tube brush with short handle and loop end.
