1-1/2" CN Style Connector Check Valve with 3.50 psi Cracking Pressure
1-1/2" CN Style Connector Check Valve with 3.50 psi Cracking Pressure
SKU:CNA-f19700
High-quality 1-1/2" CN Style Connector Check Valve with 3.50 psi Standard Cracking Pressure, adaptable for various applications.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
1-1/2" CN Style Connector Check Valve with 3.50 psi Cracking Pressure
$129.99
Quantity: 1
Claim Your Seller Account
1-1/2" CN Style Connector Check Valve with 3.50 psi Cracking Pressure
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 1-1/2" CN Style Connector Check Valve is a versatile valve designed for various applications. Made in the USA by Check-All®, this valve features National Pipe Thread (NPT) Threads and a 3.50 psi Standard Cracking Pressure. Constructed from high-quality 316 Stainless Steel as standard, with options for different materials like Alloy 20, Brass, and more, this valve offers durability and corrosion resistance. The valve is adaptable for low-pressure relief or vacuum breaker functions, making it suitable for a range of industrial settings. With certifications like CE PED and ISO 9001, this valve meets stringent quality standards.
Product Specifications
Note
Made in USA.
Specifications Body Material
316 Stainless Steel = SS | Alloy 20 = A2 | Alloy B = HB | Alloy C-276 = HC | Brass = BR | Carbon Steel = CS | Monel® 400 or Alloy R405 = MO | Titanium = TI
Specifications Body Material Availability
316 Stainless Steel (SS) - Standard | Alloy 20 (A2) - Semi-Standard | Alloy B (HB) - Contact the factory for these or other materials | Alloy C-276 (HC) - Semi-Standard | Brass (BR) - Standard | Carbon Steel (CS) - Standard | Monel® 400 or Alloy R405 - Semi-Standard | Titanium (TI) - Contact the factory for these or other materials
Specifications Certifications
European Conformity (CE) PED 2014/68/EU Complaint | International Organization for Standardization (ISO 9001) Certified
Specifications Nominal Pipe Size
1-1/2 in
Specifications Non Shock Pressure Rating At 100 Degree Fahrenhei
3000 psig
Specifications Note For Material
Listed above are the most common material selections. Please contact the factory for additional options.
Specifications Seat Material
"Metal-to-Metal" = MT | Aflas® = AS | Buna-N = BN | Ethylene Propylene Diene Monomer (EPDM) = EP (EP seats not recommended for use with Carbon Steel valves.) | Fluoro-Elastomer (FKM) = VT | Neoprene = NE | Perfluoroelastomer = KZ | Polytetrafluoroethylene (PTFE) = TF
Specifications Size Code
J
Specifications Special Options
T = FEP Encapsulated Spring (Contact the factory for more options)
Specifications Spring Material
17-7PH Stainless Steel = PH | 316 Stainless Steel = SS | Alloy B = HB | Alloy C-276 = HC | Inconel® X750 or Alloy X750 = IX | Monel® 400 = MO | Titanium = TI
Specifications Standard Cracking Pressure
3.50 psi
Specifications Valve Style
National Pipe Thread (NPT) Threads = CN
