1/16 Inch (in) Diameter and 1 x 19 Strand Non Flexible Bare Aircraft Cable and Wire Rope

Name: 1/16 Inch (in) Diameter and 1 x 19 Strand Non Flexible Bare Aircraft Cable and Wire Rope
Brand: Sandin Manufacturing
SKU: 1X1-ce5140
Price: 49.99 USD
Availability: OutOfStock

SKU:1X1-ce5140

N/A

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Sandin Manufacturing offers an extensive variety of aircraft cable and wire rope. As a premier supplier of strand, aircraft cable and wire rope Sandin Manufacturing has a large inventory for immediate shipment to any location. We stock bright, galvanized, and stainless steel materials. From the smallest strands to the large diameter wire ropes, Sandin manufacturing is here to fulfill your requirements.Most commonly used for standing rigging on sailboats, guy wire and push pull assemblies. Stainless steel is widely used in the cable railing industry.

Product Specifications

Additional Information

Bright Wire Rope is available in a variety of constructions and diameters. Typical constructions are 6 x 19, 6 x 25, and 6 x 37. Rotation resistant 19 x 7 wire ropes are also available.Galvanized cables and wire ropes are a great economical choice. They offer corrosion resistance at an affordable price. Galvanized coating is available in most strands, cables and wire ropes.Stainless Steel Type 302/304 is the most widely used of the stainless steel offerings. It offers good corrosion resistance and breaking strengths comparable to galvanized cable.Stainless Steel Type 316 has extra high corrosion resistance. It is often used in harsh environments where highly corrosive atmospheres are present. This alloy is commonly used in marine environments and offers excellent protection. The breaking strengths are typically 10% less than type 302/304 alloys.Sandin manufacturing also offers other alloys such as phosphorous bronze, monel, and inconel. If you don't see what you are looking for please feel free to contact our technical sales team.

Specifications Applications

Aircraft | Guy Wire | Push Pull Assemblies | Standing Rigging on Sailboats

Specifications Bare Cable Diameter

1/16 in

Specifications Coating

Galvanized

Specifications Conductor Material

Type 302 Stainless Steel | Type 304 Stainless Steel | Type 316 Stainless Steel

Specifications Construction

1 x 19

Specifications Galvanized Weight Per 1000 Feet Ft Length

8.5 lb

Specifications Industry Standards

Commercial Grade RR-W-410 | Military Specification (MIL-DTL-87161)

Specifications Minimum Galvanized Rated Breaking Strength

500 lb

Specifications Minimum Stainless Steel Rated Breaking Strength

500 lb

Specifications Stainless Steel Weight Per 1000 Feet Ft Length

8.5 lb

Specifications Type

Bare | Stranded

1/16 Inch (in) Diameter and 1 x 19 Strand Non Flexible Bare Aircraft Cable and Wire Rope
