1/2" CR Style Connector Check Valve - 1.50 PSI Cracking Pressure
1/2" CR Style Connector Check Valve - 1.50 PSI Cracking Pressure
SKU:CNA-3eb71f
Premium 1/2" CR Style Connector Check Valve with 1.50 PSI Cracking Pressure, Certified to Meet CE and ISO 9001 Standards
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
1/2" CR Style Connector Check Valve - 1.50 PSI Cracking Pressure
$59.99
Quantity: 1
Claim Your Seller Account
1/2" CR Style Connector Check Valve - 1.50 PSI Cracking Pressure
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 1/2" CR Style Connector Check Valve is a high-quality product designed for installations requiring a check valve with male pipe threads. Made from premium 316 Stainless Steel, it offers exceptional durability and reliability. With a standard cracking pressure of 1.50 psi, this valve is versatile and can also function as a low-pressure relief valve or vacuum breaker. Certified to meet European Conformity (CE) PED 2014/68/EU and ISO 9001 standards, this valve ensures superior performance and compliance in various applications. Made in the USA, it is a top choice for demanding industrial environments.
Product Specifications
Note
Made in USA.
Specifications Body Material
316 Stainless Steel = SS | Alloy 20 = A2 | Alloy B = HB | Alloy C-276 = HC | Brass = BR | Carbon Steel = CS | Monel® 400 or Alloy R405 = MO | Titanium = TI
Specifications Body Material Availability
316 Stainless Steel (SS) - Standard | Alloy 20 (A2) - Semi-Standard | Alloy B (HB) - Contact the factory for these or other materials | Alloy C-276 (HC) - Semi-Standard | Brass (BR) - Standard | Carbon Steel (CS) - Standard | Monel® 400 or Alloy R405 - Semi-Standard | Titanium (TI) - Contact the factory for these or other materials
Specifications Certifications
European Conformity (CE) PED 2014/68/EU Complaint | International Organization for Standardization (ISO 9001) Certified
Specifications Nominal Pipe Size
1/2 in
Specifications Non Shock Pressure Rating At 100 Degree Fahrenhei
3000 psig
Specifications Note For Material
Listed above are the most common material selections. Please contact the factory for additional options.
Specifications Seat Material
"Metal-to-Metal" = MT | Aflas® = AS | Buna-N = BN | Ethylene Propylene Diene Monomer (EPDM) = EP (EP seats not recommended for use with Carbon Steel valves.) | Fluoro-Elastomer (FKM) = VT | Neoprene = NE | Perfluoroelastomer = KZ | Polytetrafluoroethylene (PTFE) = TF
Specifications Size Code
D
Specifications Special Options
T = FEP Encapsulated Spring (Contact the factory for more options)
Specifications Spring Material
17-7PH Stainless Steel = PH | 316 Stainless Steel = SS | Alloy B = HB | Alloy C-276 = HC | Inconel® X750 or Alloy X750 = IX | Monel® 400 = MO | Titanium = TI
Specifications Standard Cracking Pressure
1.50 psi
Specifications Valve Style
International Organization for Standardization (ISO) 7 R Threads = CR
