1.250 Inch Bore Diameter Air Flow Nozzle - Aluminum
1.250 Inch Bore Diameter Air Flow Nozzle - Aluminum
SKU:AIR-d6723e
Precision-engineered 1.250 Inch Bore Diameter Air Flow Nozzle for accurate airflow calibration, meets AMCA/ANSI standards.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
1.250 Inch Bore Diameter Air Flow Nozzle - Aluminum
$45.99
Quantity: 1
Claim Your Seller Account
1.250 Inch Bore Diameter Air Flow Nozzle - Aluminum
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 1.250 Inch Bore Diameter Air Flow Nozzle is precision-engineered by Helander, a leading air calibration nozzle producer. Constructed from aluminum with a #4 Brush Finish, this nozzle complies with AMCA/ANSI standards. With capabilities in machining, spinning, and welding, it offers a tight tolerance of ±0.001 in. Ideal for air flow calibration, it meets industry requirements and can be customized for specific needs. Get accurate airflow measurement with this durable and reliable air flow nozzle.
Product Specifications
Note Note
Standard nozzle flanges do not come with a bolt hole pattern. Blank material thickness will thin in the spinning process and the final part wall thickness will vary.
Specifications For Air Flow Nozzles Approximate Clearance Hole
2.918 in
Specifications For Air Flow Nozzles Approximate Flange Diameter
5.500 in
Specifications For Air Flow Nozzles Blank Material
Aluminum
Specifications For Air Flow Nozzles Blank Material Thickness
0.125 in
Specifications For Air Flow Nozzles Bore Diameter
1.250 in
Specifications For Air Flow Nozzles Capabilities Appliedprocesse
Machining | Spinning | Welding
Specifications For Air Flow Nozzles Delivery Location
International
Specifications For Air Flow Nozzles Industry For Use
Air Flow Calibration
Specifications For Air Flow Nozzles Material Finish
#4 Brush Finish
Specifications For Air Flow Nozzles Material Thickness
0.050 to 0.250 in
Specifications For Air Flow Nozzles Material Used
Aluminum
Specifications For Air Flow Nozzles Standards Met
AMCA | ANSI
Specifications For Air Flow Nozzles Standard Delivery Time
2 to 12 Weeks
Specifications For Air Flow Nozzles Tightest Tolerance
0.001 in
Specifications For Air Flow Nozzles Volume
1 to 100 pieces
