1" 316 Stainless Steel Basic-Check Threaded In-Line Check Valve

1" 316 Stainless Steel Basic-Check Threaded In-Line Check Valve

INL-319be2

Versatile 1" 316 SS Basic-Check In-Line Check Valve for reliable and low-maintenance service. Compliant with ANSI & MSS standards.

$149.99
$149.99
Sale

Initiate Order

1" 316 Stainless Steel Basic-Check Threaded In-Line Check Valve

1" 316 Stainless Steel Basic-Check Threaded In-Line Check Valve

$149.99

Quantity: 1

Claim Your Seller Account

1" 316 Stainless Steel Basic-Check Threaded In-Line Check Valve

1" 316 Stainless Steel Basic-Check Threaded In-Line Check Valve

$149.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The 1" 316 SS BSE Style Basic-Check® Threaded In-Line Check Valve is a versatile non-slam valve suitable for a wide range of liquids, steam, and gases. With features like stainless steel construction, precision-lapped metal-to-metal sealing, and easy maintenance, this valve ensures reliable performance. It is ideal for applications in autoclaves, chemical lines, compressor discharge, and more. Compliant with ANSI B1.20.1 and MSS SP-25 standards, this valve offers exceptional durability and functionality for various industrial settings.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Application 0
Autoclaves | Boiler Feed & Discharge | Chemical Lines | Compressor Discharge | Condensate Lines | Cookers | Cooling Towers | Crude & Refined Product Lines | Cryogenics | Digester | Evaporators | Fly Ash System | Generator Inlet & Discharge | Hydraulic Lines | Metering Pumps | Mine Dewatering | Nitrogen Purge | Process Lines | Pump Discharge | Refrigeration | Steam Lines | Vacuum Breaker | Water Lines | Water Treatment
Codes And Standards Ansi
B1.20.1
Codes And Standards Mss
SP-25
Features 0
1/4" to 2 1/2" Line size450 to 6000 CWPThreaded endsStainless Steel ConstructionSpring-assisted silent closingHorizontal or vertical installationTight shut-off - lapped disc & seatEasy MaintenanceVersatile
Materials Of Construction Disc
316 SS
Materials Of Construction Guard
17-4 SS
Materials Of Construction Retaining Ring
316 SS
Materials Of Construction Seat
303 SS
Materials Of Construction Spring
Inconel®
Options 0
Inconel® 750 Spring Soft seat
Specifications Approx Net Weight Each
1.25 lb | 0.6 kg
Specifications Cold Working Pressure
0 psig | 1500 psig | 0 barg | 103 barg
Specifications Cv
23.1
Specifications Ends
NPT (Threaded)
Specifications Friction Loss Feet Of Pipe
7
Specifications Friction Loss Meter Of Pipe
2.1
Specifications Line Size Inlet Fnpt A
1.00 in
Specifications Outside Thread Mnpt B
2.00 in
Specifications Series
Basic-Check®
Specifications Size
1.00 in | DN 25
Specifications Style
BSE
Specifications Valve Cracking Pressure
0.36 psi | 0.025 bar | 10.1 in.water | 257 mm.water | 18.8 mmHg
Specifications Valve Cracking Pressure Tolerance
±10%
