1.375 Inch (in) Diameter Acetal Rod
1.375 Inch (in) Diameter Acetal Rod
SKU:ACE-db2b41
N/A
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
1.375 Inch (in) Diameter Acetal Rod
$49.99
Quantity: 1
Claim Your Seller Account
1.375 Inch (in) Diameter Acetal Rod
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Acetal is white in its natural color which makes it ideal in food related applications. It is also available in black. There are 2 basic types of acetal: Homopolymer and Copolymer.
Product Specifications
Additional Information
Homopolymer is best known by the trade name Acetal. It has slightly better mechanical and thermal properties than the copolymer. It is available in the following grades:Glass-Filled - This increases the stiffness, mechanical properties, and dimensional stability of unfilled acetal.Acetal AF - This is PTFE filled Acetal. It has better lubricity, a lower coefficient of friction, and better wear resistance. The blend can range from 10% to 20% PTFE.Copolymer has been known in the past by the trade name Celcon® but more recently by the name Ultraform®. It sacrifices some thermal and mechanical properties when compared to the homopolymer, but carries an important advantage. Copolymer does not exhibit any "center line porosity" that is common in the homopolymer.
Note
Cut to size on request.
Properties
Acetal is a widely used mechanical thermoplastic. It offers a unique combination of cost effective properties such as:Excellent moisture resistance.Excellent dimensional stabilityVery good rigidity & mechanical strengthLow coefficient of frictionFDA/USDA/NSF compliantContinuous use temperature of 180ºF
Specifications Color
Black | Natural
Specifications Diameter
1.375 in
Specifications Standard Length
4 ft | 8 ft | 10 ft
Specifications Tolerance
+0.005/-0 in
Specifications Weight
0.917 lb/ft²
