1.5" 316 Stainless Steel Basic-Check Threaded In-Line Check Valve

1.5" 316 Stainless Steel Basic-Check Threaded In-Line Check Valve

INL-ba638e

Versatile 1.5" 316 SS In-Line Check Valve with tight shutoff, stainless steel construction, and easy maintenance.

$299.99
$299.99
Sale

Initiate Order

1.5" 316 Stainless Steel Basic-Check Threaded In-Line Check Valve

1.5" 316 Stainless Steel Basic-Check Threaded In-Line Check Valve

$299.99

Quantity: 1

Claim Your Seller Account

1.5" 316 Stainless Steel Basic-Check Threaded In-Line Check Valve

1.5" 316 Stainless Steel Basic-Check Threaded In-Line Check Valve

$299.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The 1.5" 316 Stainless Steel Basic-Check Threaded In-Line Check Valve is a versatile non-slam valve designed to offer reliable, low-maintenance service for a wide range of liquids, steam, and gases. With a guard cage, spring, precision-lapped valve disc, and seat, this valve ensures tight shutoff for gases, steam, and liquids. It features stainless steel construction, spring-assisted silent closing, and is suitable for horizontal or vertical installation. Additional features include easy maintenance and compatibility with different pipe fittings. Ideal for various applications including autoclaves, chemical lines, and more.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Application 0
Autoclaves | Boiler Feed & Discharge | Chemical Lines | Compressor Discharge | Condensate Lines | Cookers | Cooling Towers | Crude & Refined Product Lines | Cryogenics | Digester | Evaporators | Fly Ash System | Generator Inlet & Discharge | Hydraulic Lines | Metering Pumps | Mine Dewatering | Nitrogen Purge | Process Lines | Pump Discharge | Refrigeration | Steam Lines | Vacuum Breaker | Water Lines | Water Treatment
Available Soft Seat Materials Available Soft Seat Materials
Buna-N (-70 to 250ºF) | EPDM (-75 to 300ºF) | TFE®-Viton® (-40 to 400ºF) | Viton® (-40 to 400ºF) | Zelon® (37 to 450ºF)
Codes And Standards Ansi
B1.20.1
Codes And Standards Mss
SP-25
Features 0
1/4" to 2 1/2" Line size450 to 6000 CWPThreaded endsStainless Steel ConstructionSpring-assisted silent closingHorizontal or vertical installationTight shut-off - lapped disc & seatEasy MaintenanceVersatile
Materials Of Construction Disc
316 SS
Materials Of Construction Guard
CF8M
Materials Of Construction Retaining Ring
316 SS
Materials Of Construction Seat
316 SS
Materials Of Construction Spring
316 SS
Options 0
Inconel® 750 Spring Soft seat
Specifications Approx Net Weight Each
3.75 lb | 1.7 kg
Specifications Cold Working Pressure
0 psig | 700 psig | 0 barg | 48.3 barg
Specifications Cv
57.4
Specifications Ends
NPT (Threaded)
Specifications Friction Loss Feet Of Pipe
11
Specifications Friction Loss Meter Of Pipe
3.4
Specifications Line Size Inlet Fnpt A
1.50 in
Specifications Outside Thread Mnpt B
3.00 in
Specifications Series
Basic-Check®
Specifications Size
1.50 in | DN 40
Specifications Style
BS316S
Specifications Valve Cracking Pressure
0.15 psi | 0.01 bar | 4.2 in.water | 107 mm.water | 7.8 mmHg
Specifications Valve Cracking Pressure Tolerance
±10%
