The 1.52 Specific Gravity Electro-Magnetic Interference (EMI) Shielding Composite is a cutting-edge solution designed for high heat sink and EMI shielding requirements in electrical devices, automotive components, wireless chargers, and more. With a specific gravity of 1.52 and superior conductive plastics properties, this composite offers comparable heat dissipation to Al die-casting products while providing adjustable EMI shielding effectiveness within specific frequency bands. Additionally, its lightweight nature, offering up to 55% weight reduction compared to metal, makes it a versatile and efficient choice for various applications.
Product Specifications
Additional Information
CNT is known as having excellent electrical conductivity, thermal conductivity, strength, and thermal stability. Demand for Li-ion Battery as positive electrode conductive additives has been increasing and CNT is also being used in applications such as tire treads and antistatic resins.Kumho's CNT have a highly oriented bundle structure and have been used by major battery manufacturers and tire manufacturers globally. Multiple grades of CNT are available depending on required property and each application, and we also have various types of rubber and resin compound and masterbatches.Kumho Petrochemical with one of the world's largest synthetic rubber manufacturing capacities was established in 1970 and developing their business in several fields including synthetic resins, specialty chemicals, nanocarbons, energy, and building materials.Major application with Kumho's CNTLi-ion Battery as positive electrode conductive additives for automotiveTire treadsElectronic Parts TraysConductive coatingElectro-Magnetic Interference (EMI) Shielding CompositeConductive resin/rubber
Properties Electro Magnetic Interference Emi Shield 32 M
60~65 dB
Properties Flexural Modulus 5 Millimeter Mmminitue Min
70,000 kgf/cm²
Properties Flexural Strength 5 Millimeter Mmminitue Min
700 kgf/cm²
Properties Izod Impact Notched 32 Millimeter Mm
3.0 kgf·cm/cm
Properties Specific Gravity
1.52
Properties Tensile Strength 5 Millimeter Mmminitue Min
400 kgf/cm²
Properties Test Method For Electro Magnetic Interference
American Society for Testing and Materials (ASTM) D4935
Properties Test Method For Flexural Modulus 5 Millimeter
American Society for Testing and Materials (ASTM) D790
Properties Test Method For Flexural Strength 5 Millimete
American Society for Testing and Materials (ASTM) D790
Properties Test Method For Izod Impact Notched 32 Millim
American Society for Testing and Materials (ASTM) D256
Properties Test Method For Specific Gravity
American Society for Testing and Materials (ASTM) D792
Properties Test Method For Tensile Strength 5 Millimeter
American Society for Testing and Materials (ASTM) D638
Properties Test Method For Thermal Conductivity
American Society for Testing and Materials (ASTM) D5470
Properties Thermal Conductivity
<10 W/m·K
