High-density Silicon Carbide granule with exceptional thermal, mechanical, and electrical properties suitable for diverse engineering applications.
Regular price
$20.99
Regular price
Sale price
$20.99
Unit price
per
Initiate Order
1
$20.99
Quantity: 1
Claim Your Seller Account
1
$20.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 1 Nominal Granule Size Silicon Carbide Hot-Pressed Granule is a high-density material known for its exceptional mechanical, thermal, and electrical properties. It is manufactured by Goodfellow Corp. Ideal for various engineering applications, this granule exhibits excellent resistance to chemicals and high temperatures. With a Vickers hardness of 2400 to 2800 Kgf mm-2 and a compressive strength of 1000 to 1700 MPa, it offers outstanding durability. Its thermal conductivity of 90.00 to 160.00 W m-1K-1 makes it suitable for demanding thermal applications while maintaining stability at temperatures up to 2950.00 ºC. This product aligns with strict industry standards for quality and performance, meeting the needs of both consumer and institutional buyers.
Product Specifications
Chemical Resistance Alkalis
Good | Poor
Chemical Resistance Concentrated Acids
Good
Chemical Resistance Dilute Acids
Good
Chemical Resistance Halogens
Good | Poor
Chemical Resistance Metals
Fair
Electrical Properties Dielectric Constant
40.0
Electrical Properties Volume Resistivity At 25 Degree Celsius C
103 to 105 µΩ·cm
Material Material
Silicon Carbide - Hot-pressedSilicon Carbide. Hot Pressed Silicon Carbide is a high density, high strength material which has been used in refractory applications for many years. It is now used for a wide range of engineering applications. Hot Pressed Silicon Carbide can be processed to close tolerances and into fairly complex shapes. Silicon Carbide can be highly polished and has potential for space-based mirrors, because of its high specific strength and stiffness compared with those of glass.
Mechanical Properties Hardness Vickers
2400 to 2800 Kgf mm-2
Mechanical Properties Shear Strength
210 to 380
Mechanical Properties Tensile Modulus
200.00 to 500.00 GPa
Mechanical Properties Tensile Strength
400.00 MPa
Physical Properties Apparent Porosity
0.00 %
Physical Properties Density
3.150 g·cm-3
Pultrusion Compressive Strength
1000 to 1700 MPa
Specifications Form
Granule
Specifications Nominal Granule Size
1
Specifications Weight
10 to 100 g
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
4.500 x10-6 K-1
Thermal Properties Melting Point
2650.00 to 2950.00 ºC
Thermal Properties Specific Heat At 25 Degree Celsius C Temperat
670.0 to 710.0 J K-1 kg-1
Thermal Properties Thermal Conductivity At 20 Degree Celsius C T
90.00 to 160.00 W m-1K-1
Thermal Properties Upper Continuous Use Temperature
1500 to 1650 ºC
Type Type
CeramicCeramics are non-metallic, non-organic materials. They exhibit excellent resistance to high temperatures. Although they have comparatively low densities, they are extremely hard but tend to be brittle. They show good resistance to both abrasives and chemicals.
