1" PVC 3-Way Lateral True Union Ball Valves w/FPM O-Rings, Flanged Connections
1" PVC 3-Way Lateral True Union Ball Valves w/FPM O-Rings, Flanged Connections
SKU:TRU-8ad90e
Precision control with 1" PVC 3-Way True Union Ball Valve. PVC body, FPM o-rings, flanged connections. Ideal for diverse applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 1" PVC 3-Way Lateral True Union Ball Valve from our LA Series is designed for precise flow control, allowing diversion from the center port to either side without an OFF position. Crafted with durable PVC and FPM o-rings, it ensures reliable performance in diverse applications. With robust flanged end connections and a Cv Factor of 10, this valve is rated @150PSI, meeting stringent institutional procurement standards. Sizes range from 1/2" to 6", providing versatility and efficiency in fluid handling.

Product Specifications
Specifications A
3.00 in | 76.20 mm
Specifications B
2.98 in | 75.69 mm
Specifications Body Material
PVC
Specifications C
4.14 in | 105.16 mm
Specifications Cv Factor
10
Specifications E
4.00 in | 101.60 mm
Specifications End Connection
Flanged
Specifications F
4.77 in | 121.16 mm
Specifications G
8.50 in | 215.90 mm
Specifications H
3.23 in | 82.04 mm
Specifications Seals
FPM
Specifications Size
1"
