100R1AT Hydraulic Single Braid - Medium Pressure Hose Bulk Coils

Name: 100R1AT Hydraulic Single Braid - Medium Pressure Hose Bulk Coils
Brand: Seal Fast, Inc.
SKU: HOS-4f0a86
Price: 299.99 USD
Availability: OutOfStock

SKU:HOS-4f0a86

Premium 100R1AT Hydraulic Single Braid Hose - Ideal for mineral oil and glycol base liquids. Meets SAE J517 100R1AT standards. Operating range: -40 to +250 ºF.

$299.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 100R1AT Hydraulic Single Braid hose is a top-tier solution for mineral oil and glycol base liquids, offering exceptional performance in hydraulic applications. Meeting and surpassing SAE J517 100R1AT standards, this hose ensures reliability and durability. With a working pressure of 1000 psi and a burst pressure of 4000 psi, it provides the strength needed for medium-pressure hydraulic systems. Featuring oil and weather-resistant synthetic rubber cover, oil-resistant synthetic rubber tube, and one steel wire braid reinforcement, this hose operates efficiently in temperatures ranging from -40 to +250 ºF. Ideal for a variety of industrial uses, this product is sold in bulk coils for convenience and flexibility.

Product Specifications

Specifications Bend Radius

12 in

Specifications Burst Pressure 70

4000 psi

Specifications Cover

Oil and Weather Resistant Synthetic Rubber

Specifications Id

1 in

Specifications Od

1.35 in

Specifications Package Type

Feet

Specifications Reinforcement

One Steel Wire Braid

Specifications Temperature Range

-40 to +250 ÂºF

Specifications Tube

Oil Resistant Synthetic Rubber

Specifications Weight Per 100 Foot

55.8 lb

Specifications Working Pressure

1000 psi
