110V DC Control Relay - T-Range
110V DC Control Relay - T-Range
SKU:REL-ed2546
Reliable and compliant 110V DC Control Relay for industrial applications, featuring precise control and durability.
Regular price
$55.00
Regular price
Sale price
$55.00
Unit price
per
Initiate Order
110V DC Control Relay - T-Range
$55.00
Quantity: 1
Claim Your Seller Account
110V DC Control Relay - T-Range
$55.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The T-Range 110V DC Control Relay by Shamrock Controls is a reliable solution for various industrial applications, offering exceptional performance and durability. With contacts conforming to IEC60947-1, IEC60947-5, and VDE0660 standards, this relay provides protection against direct finger contact and operates efficiently in ambient temperatures ranging from -40 to +80°C. Approved by CSA and UL, it ensures safe and compliant operations. The relay features a rated insulation voltage of 690V, with a permissible control circuit voltage of 12 to 600V. It offers precise control with operating times ranging from 6 to 48 ms, making it ideal for critical control circuit applications.
Product Specifications
Operating Power Of Contactor With Alternating Current Ac Supply
Electrical life (upto 3600 Operating cycles/hr) on an inductive load such as the coil of an electromagnet making power (cos ø 0.7) - 10 times the power broken (cos ø 0.4)Breaking limits of contacts valid for maximum of 50 operating cycles at 10 s intervals (breaking power = making power (cos ø 0.7)Electrical Life of Contacts:For 1 million Operating Cycles (2a)For 3 million Operating Cycles (2b)For 10 million Operating Cycles (2c)Thermal Limit
Operating Power Of Contactor With Direct Current Dc Supply Categ
33 V·A
