Enhance your industrial processes with the 1117 High Force Super Air Nozzle. Crafted from durable Zinc Aluminum alloy, this nozzle delivers a powerful 9.4 lb blowing force at 80 psig pressure, improving chip removal, part cooling, and more. With a noise level of 102 dBA and compact design, it ensures enhanced production efficiency, safety, and compliance with OSHA noise and pressure regulations. Save on compressed air costs and boost your operations with this high-performance solution.
Product Specifications
Specifications Advantages
10 dBA Average Noise Reduction | Compact | Conserve Compressed Air | Improved Blowoff Performance | Improved Production | Improved Safety | Meets OSHA Noise Level Requirements | Meets OSHA Pressure Requirements | Reduced Compressed Air Cost
Specifications Air Consumption
188 SCFM | 5324 SLPM
Specifications Applications
Air Assist | Chip Removal | Fiber Conveying | Liquid Blowoff | Material Conveying | Part Cleaning | Part Cooling | Part Drying | Part Ejection
Specifications Force
9.4 lb | 4252 g
Specifications Inlet
1-1/4 MNPT
Specifications Material
Zinc Aluminum alloy
Specifications Note
Force measured at 12" (305 mm) from target
Specifications Pressure
80 psig | 5.5 bar
Specifications Sound Level
102 dBA
