12.7mm Aluminum/Magnesium/Silicon Tube
12.7mm Aluminum/Magnesium/Silicon Tube
SKU:ALU-a13d97
High-quality 12.7mm Aluminum/Magnesium/Silicon Tube for industrial applications, precise dimensions, and reliable performance.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
12.7mm Aluminum/Magnesium/Silicon Tube
$45.99
Quantity: 1
Claim Your Seller Account
12.7mm Aluminum/Magnesium/Silicon Tube
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 12.7mm Aluminum/Magnesium/Silicon Tube by Goodfellow Corp. is a high-quality, hard temper tube with precise dimensions (12.7mm OD, 1.22mm wall thickness) suitable for various industrial applications. With exceptional mechanical properties (tensile strength up to 325.00 MPa) and thermal conductivity (180.00 - 195.00 W m-1K-1), this tube offers reliable performance. Its aluminum/magnesium/silicon alloy composition ensures excellent electrical resistivity (3.4 - 3.8 µΩ·cm) and low thermal expansion. Compliant with industry standards, this tube is ideal for government and institutional procurement needs.
Product Specifications
Electrical Properties Electrical Resistivity
3.4 to 3.8 µΩ·cm
Electrical Properties Temperature Coefficient
0.00310 to 0.00350 k-1
Material Material
Aluminum/Magnesium/SiliconAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities).Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
Mechanical Properties Elongation At Break
< 20.0 %
Mechanical Properties Hardness Brinell
65 to 95
Mechanical Properties Modulus Of Elasticity
69.0 GPa
Mechanical Properties Tensile Strength
245.00 to 325.00 MPa
Physical Properties Density
2.690 g·cm-3
Specifications Form
Tube
Specifications Inside Diameter
10.26 mm
Specifications Length
100 to 1000 mm
Specifications Outside Diameter
12.7 mm
Specifications Temper
Hard
Specifications Wall Thickness
1.22 mm
Thermal Properties Coefficient Of Thermal Expansion At 20 To 100
23.000 x10-6 K-1
Thermal Properties Thermal Conductivity At 23 Degree Celsius C T
180.00 to 195.00 W m-1K-1
Tolerances Tolerance For 100 Millimeter Mm Length Round
-1 % | +5 %
Tolerances Tolerance For 2 Millimeter Mm Outside Diameter
0.5 mm
Tolerances Tolerance For 5 Millimeter Mm Outside Diameter
5 %
Tolerances Wall Thickness Tolerance
10 %
Type Type
AlloyAlloys are mixtures of a metal with other elements, the precise combination being governed by the required properties. Alloys are generally considered to be metallic in nature i.e. they have good thermal and electrical conductivities). Alloys can be manufactured by various routes, the most widely used being to melt the constituents together and to cool the resultant mixture to form a single or multi-phase solid.
