12 Inch Urethane Compression Spring
12 Inch Urethane Compression Spring
SKU:URE-dd253a
High-performance 12-inch Urethane Compression Spring for corrosion-resistant, high load applications.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
12 Inch Urethane Compression Spring
$45.99
Quantity: 1
Claim Your Seller Account
12 Inch Urethane Compression Spring
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Ideal for applications requiring corrosion, vibration, and magnetism resistance, the 12-inch Urethane Compression Spring offers high load-carrying capability, dielectric strength, and non-magnetic properties. With abrasion and oil resistance, low noise, and exceptional load-bearing capacity, this compression spring is perfect for punching, stamping, and drawing dies. Its effectiveness in temperatures ranging from -30°F to 180°F, along with vibration damping and shock absorbance, makes it a reliable choice for various engineering applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Additional Information
Because of the exceptional load bearing capacity of urethane compression springs in the shape of tubes, cylinders, rectangular pads & sheets, urethane compression springs are used very successfully in various Engineering applications such as seismic bridge bearing blocks.
Specifications Continuous Cycle Per Hour
12,000
Specifications Continuous Maximum Deflection
0 to 15 %
Specifications Conventional Heavy Duty Steel Die Spring
0 to 500 lb
Specifications Cycles Per Hour For Slow Speeds Or Short Runs
200
Specifications Hardness
80A duro
Specifications Height
1 in
Specifications Intermittent Cycles Per Hour
700
Specifications Intermittent Maximum Deflection
0 to 25 %
Specifications Length
12 in
Specifications Maximum Deflection For Slow Speeds Or Short Runs
Less than 25%
Specifications Pressure Per 18 Inch In Deflection
4,000 lb
Specifications Product Features
High load-carrying capability | High dielectric strength and non-magnetic | Protection against marring/galling | Longer life | Abrasion resistance | Oil and solvent resistance | Low noise | 100% load-bearing surface | Bondable to mating parts | Effectiveness between - 30°F and 180°F | Vibration damping and shock absorbance
Specifications Shape
Bar
Specifications Urethane Bar Stock Weight
0 to 90,000 lb
Specifications Urethane Slab Stock Weight
Unlimited
Specifications Urethane Springs Weight
0 to 2,600 lb
Specifications Width
1.000 in
