12 Inch Urethane Compression Spring (DT-35-12-22)
12 Inch Urethane Compression Spring (DT-35-12-22)
SKU:URE-e59406
Reliable 12-inch urethane compression spring for industrial use. High load capacity, corrosion resistance, and durability.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
12 Inch Urethane Compression Spring (DT-35-12-22)
$49.99
Quantity: 1
Claim Your Seller Account
12 Inch Urethane Compression Spring (DT-35-12-22)
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The DT-35-12-22 12-inch Urethane Compression Spring is designed for applications where corrosion, vibration, and magnetism restrict the use of traditional steel springs. With a hardness of 80A duro, it offers high load-carrying capacity, dielectric strength, protection against marring/galling, and more. This urethane spring is oil and solvent resistant, operates effectively between -30°F and 180°F, and provides vibration damping and shock absorbance. Ideal for punching, stamping, and drawing dies, it ensures longer life and low noise levels.
Product Specifications
Specifications Additional Information
P.P.CâS urethane spring material is a polyether-elastomer that reacts similarly to an incompressible fluid. The volume of material moved by compression is displaced laterally in the form of bulging sides. An approximation to the change in diameter of one of our standard cylindrical urethane springs can be made by increasing the diameter by the same amount of compression.
Specifications Continuous Cycle Per Hour
12,000
Specifications Continuous Maximum Deflection
0 to 15 %
Specifications Conventional Heavy Duty Steel Die Spring
0 to 500 lb
Specifications Cycles Per Hour For Slow Speeds Or Short Runs
200
Specifications Hardness
80A duro
Specifications Height
2 in
Specifications Intermittent Cycles Per Hour
700
Specifications Intermittent Maximum Deflection
0 to 25 %
Specifications Length
12 in
Specifications Maximum Deflection For Slow Speeds Or Short Runs
Less than 25%
Specifications Pressure Per 18 Inch In Deflection
3,700 lb
Specifications Product Features
High load-carrying capability | High dielectric strength and non-magnetic | Protection against marring/galling | Longer life | Abrasion resistance | Oil and solvent resistance | Low noise | 100% load-bearing surface | Bondable to mating parts | Effectiveness between - 30°F and 180°F | Vibration damping and shock absorbance
Specifications Shape
Bar
Specifications Urethane Bar Stock Weight
0 to 90,000 lb
Specifications Urethane Slab Stock Weight
Unlimited
Specifications Urethane Springs Weight
0 to 2,600 lb
Specifications Width
2 in
