12 kVDC Non-Shielded Straight Cable Assembly (Rear Mount) - PeeWee Series
12 kVDC Non-Shielded Straight Cable Assembly (Rear Mount) - PeeWee Series
SKU:HIG-762621
Elevate your high voltage connections with the 12 kVDC Non-Shielded Straight Cable Assembly - precision design for demanding applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
12 kVDC Non-Shielded Straight Cable Assembly (Rear Mount) - PeeWee Series
$49.99
Quantity: 1
Claim Your Seller Account
12 kVDC Non-Shielded Straight Cable Assembly (Rear Mount) - PeeWee Series
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your high voltage interconnection needs with the 12 kVDC Non-Shielded Straight Cable Assembly from the PeeWee Series. Designed for dense electronic packaging, this assembly boasts a right angle double-ended receptacle cable assembly, push-pull coupling style, and a rear mount panel mounting style. With an altitude rating of 70,000 ft and an operating temperature range of -55 to 125°C, this non-standard part ensures reliable interconnections in demanding environments. The encapsulated back end with silicone rubber and etched FEP wire insulation add to its durability and safety. Ideal for lasers, photomultipliers, TWT, and power supplies.
Product Specifications
Application 0
LasersPhotomultipliersTWTPower Supplies
Body Properties Coupling Nut Material
Plastic
Cable Wire Properties Wire Diameter
0.050 in
Contact Properties Contact Diameter
0.030 in | 0.762 mm
Contact Properties Contact Size
24 AWG
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Right Angle Double Ended Receptacle Cable Assembly
Specifications Coupling Style
Push-Pull
Specifications Current Rating
1.6 Amp
Specifications Encapsulation
Back end of connector is encapsulated with silicone rubber
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic
Specifications Mating Compatibility
Mates with all threaded Pee-Wee series coupling plug cable assemblies.
Specifications Operating Temperature
-55 to 125 ºC
Specifications Panel Mounting Style
Rear Mount
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
No
Specifications Series
PeeWee
Specifications Standardnon Standard
Non-standard Part
Specifications Test Voltage
18 kVDC
Specifications Voltage Rating
12 kVDC
Specifications Wire Insulation
Etched FEP W/NOMEX
