12 kVDC PeeWee Right Angle Cable Assembly
12 kVDC PeeWee Right Angle Cable Assembly
SKU:HIG-3e9f5b
High-voltage 12 kVDC PeeWee Right Angle Cable Assembly for compact and demanding applications. Double-ended design with sealing technology for reliable performance.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
12 kVDC PeeWee Right Angle Cable Assembly
$39.99
Quantity: 1
Claim Your Seller Account
12 kVDC PeeWee Right Angle Cable Assembly
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 12 kVDC PeeWee Right Angle Cable Assembly, part of the PeeWee series, features a double-ended right angle plug design for high-voltage applications in compact spaces. Seal high voltage at reduced atmospheric pressure with Teledyne Reynolds' Advanced Interface™ method. Rated at 12 kVDC up to 70,000 feet with a wide temperature range of -55°C to 125°C, this non-standard assembly ensures reliable performance in demanding environments. Backed by plastic insulator material, encapsulated with silicone rubber, and compatible with various PeeWee series receptacles and cable assemblies.
Product Specifications
Application 0
LasersPhotomultipliersPower SuppliesTWT
Body Properties Coupling Nut Material
Plastic
Cable Wire Properties Wire Diameter
0.050 in
Contact Properties Contact Diameter
0.030 in | 0.762 mm
Contact Properties Contact Size
24 AWG
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Double-Ended Right Angle Plug Cable Assembly
Specifications Coupling Style
Threaded
Specifications Current Rating
1.6 Amp
Specifications Encapsulation
Back end of connector is encapsulated with silicone rubber
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic
Specifications Mating Compatibility
Mates with all Pee-Wee series threaded receptacles and threaded receptacles cable assemblies.
Specifications Operating Temperature
-55 to 125 ºC
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
N/A
Specifications Series
PeeWee
Specifications Standardnon Standard
Non-standard Part
Specifications Test Voltage
18 kVDC
Specifications Voltage Rating
12 kVDC
Specifications Wire Insulation
Etched FEP
