12 kVDC PeeWee Series Front Mount Receptacle Connector
12 kVDC PeeWee Series Front Mount Receptacle Connector
SKU:HIG-2ce60f
High-voltage PeeWee Series connector, 12 kVDC, Front Mount Panel, Push-Pull Coupling, Altitude-rated, -55 to 125°C
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
12 kVDC PeeWee Series Front Mount Receptacle Connector
$29.99
Quantity: 1
Claim Your Seller Account
12 kVDC PeeWee Series Front Mount Receptacle Connector
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 12 kVDC PeeWee Series Front Mount Receptacle Connector is a subminiature, high-voltage connector designed for dense electronic packaging in high voltage applications. Featuring Teledyne Reynold's Advanced Interface™ sealing method, this connector is rated at 12 kVDC at altitudes up to 70,000 feet, with a wide temperature range of -55°C to 125°C. With a push-pull coupling style and compatibility with all non-threaded Pee-Wee series plug assemblies, this connector ensures secure connections in demanding environments. The plastic insulator material and front mount panel design make it reliable and easy to install, ideal for lasers, photomultipliers, power supplies, and TWT applications.
Product Specifications
Application 0
LasersPhotomultipliersPower SuppliesTWT
Body Properties Coupling Nut Material
Plastic
Contact Properties Contact Diameter
0.030 in | 0.762 mm
Contact Properties Contact Size
24 AWG
Contact Properties Contact Type
Male
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Receptacle
Specifications Coupling Style
Push-Pull
Specifications Current Rating
1.6 Amp
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic
Specifications Mating Compatibility
Mates with all non-threaded Pee-Wee series plug assemblies.
Specifications Operating Temperature
-55 to 125 ºC
Specifications Panel Mounting Style
Front Mount
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
No
Specifications Series
PeeWee
Specifications Standardnon Standard
Standard Part
Specifications Test Voltage
18 kVDC
Specifications Voltage Rating
12 kVDC
